Broadcom Simplex Single Mode Fibre Optic Cable, 1.06mm, Black, 1m
- RS Stock No.:
- 755-9953
- Mfr. Part No.:
- HFBR-RLS001Z
- Brand:
- Broadcom
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 755-9953
- Mfr. Part No.:
- HFBR-RLS001Z
- Brand:
- Broadcom
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Broadcom | |
| Length | 1m | |
| Propagation Mode | Single Mode | |
| Terminated/Unterminated | Terminated | |
| Core Diameter | 1.06mm | |
| Sheath Colour | Black | |
| Cable Construction | Simplex | |
| Maximum Operating Temperature | +85°C | |
| Attenuation | 0.27 dB/m | |
| Sheath Material | Polyethylene PE | |
| Minimum Operating Temperature | -40°C | |
| Minimum Bend Radius | 35 mm | |
| Maximum Pulling Tension | 50N | |
Select all | ||
|---|---|---|
Brand Broadcom | ||
Length 1m | ||
Propagation Mode Single Mode | ||
Terminated/Unterminated Terminated | ||
Core Diameter 1.06mm | ||
Sheath Colour Black | ||
Cable Construction Simplex | ||
Maximum Operating Temperature +85°C | ||
Attenuation 0.27 dB/m | ||
Sheath Material Polyethylene PE | ||
Minimum Operating Temperature -40°C | ||
Minimum Bend Radius 35 mm | ||
Maximum Pulling Tension 50N | ||
HFBR-RXXYYYZ Series Fibre Optic Cable Assemblies
This family of fibre optic cable assemblies, from Avago Technologies, consist of a POF cable with connectors attached. They are available in a variety of lengths with both simplex and duplex connector options. The HFBR-RXXYYYZ series is made up from plastic fibre optic cables that are constructed from a single step index fibre sheathes in a polyethylene jacket. The duplex fibre is comprised of two simplex fibres that are joined with a zipcord web.
Features and Benefits
• Compatible with Avago Versatile Link Family of connectors and other fibre optic components.
• 1 mm diameter Plastic Optical Fibre (POF) in 2 grades: - Standard POF with 0.22 dB/m typical attenuation (-40°C to 85°C).
• High performance Extra Low Loss POF with 0.19 dB/m typical attenuation (-40°C to 85°C).
• 1 mm diameter Plastic Optical Fibre (POF) in 2 grades: - Standard POF with 0.22 dB/m typical attenuation (-40°C to 85°C).
• High performance Extra Low Loss POF with 0.19 dB/m typical attenuation (-40°C to 85°C).
Typical Applications
• Industrial data links for factory automation and plant control
• Intra-system links, board to board and rack to rack
• Telecommunication switching systems
• Propriety LANs
• Digitalised video
• Medical instruments
• High voltage isolation
• Reduction of lighting and voltage transient susceptibility
• Intra-system links, board to board and rack to rack
• Telecommunication switching systems
• Propriety LANs
• Digitalised video
• Medical instruments
• High voltage isolation
• Reduction of lighting and voltage transient susceptibility
How does Fibre Optic cable work?
Fibre optic cable works through carrying communication signals using pulses of light generated by small lasers orlight-emitting diodes (LEDs). The cable consists of one or more strands, similar in size to a human hair. The centre of each strand is called the core, this core is the pathway for light to travel. The core is surrounded by a layer of glass that reflects light inward to avoid loss of signal and allows the light to pass through bends in the cable.
Broadcom HFBR-RLS001Z Fibre Optic Cable Assembly
This HFBR-RLS001Z fibre optic cable from Broadcom has a length of 1m and its propagation mode is single. The communication channels are Simplex, the core diameter is 1.06mm and the connectors are Simplex Latching.
