RS PRO LC to LC Simplex Single Mode OS1, OS2 Fibre Optic Cable, 900μm, Yellow, 15m
- RS Stock No.:
- 172-7307
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
£18.77
(exc. VAT)
£22.52
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 51 unit(s) ready to ship
- Plus 21 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £18.77 |
| 5 - 9 | £18.04 |
| 10 - 49 | £17.31 |
| 50 - 99 | £16.60 |
| 100 + | £15.87 |
*price indicative
- RS Stock No.:
- 172-7307
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Length | 15m | |
| Connector 1 | LC | |
| Connector 2 | LC | |
| Propagation Mode | Single Mode | |
| Terminated/Unterminated | Terminated | |
| Core Diameter | 900µm | |
| Sheath Colour | Yellow | |
| Cable Construction | Simplex | |
| Fibre Type | OS1, OS2 | |
| Maximum Operating Temperature | +60°C | |
| Minimum Operating Temperature | -20°C | |
| Attenuation | 0.38 dB | |
| Standards Met | IEC 60332-1 | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Length 15m | ||
Connector 1 LC | ||
Connector 2 LC | ||
Propagation Mode Single Mode | ||
Terminated/Unterminated Terminated | ||
Core Diameter 900µm | ||
Sheath Colour Yellow | ||
Cable Construction Simplex | ||
Fibre Type OS1, OS2 | ||
Maximum Operating Temperature +60°C | ||
Minimum Operating Temperature -20°C | ||
Attenuation 0.38 dB | ||
Standards Met IEC 60332-1 | ||
- COO (Country of Origin):
- CN
Single mode patch cords are used for telecom networks and also used for high speed metropolitan and access network. The single mode patch cords are manufactured using LSZH cabless. The OS2 enhanced patch cords are terminated with optimised connectors which give optimum optical performance.
FC, LC, MTRJ, MU, SC and ST connectors
UPC and APC connectors
Low smoke zero halogen (LSZH) jacket in yellow colour
900 μm or 600 μm tight buffer
OS1/OS2 cabled fibre
Simplex and duplex assemblies
Duplex assemblies available with clips (SC and LC)
Applications
CATV / Video
Passive Optical Network PON
WDM / DWDM
FTTH
Data centres
Supports high speed multi channel video, data and voice services in metropolitan and access networks
ATM, SONET and WDM
UPC and APC connectors
Low smoke zero halogen (LSZH) jacket in yellow colour
900 μm or 600 μm tight buffer
OS1/OS2 cabled fibre
Simplex and duplex assemblies
Duplex assemblies available with clips (SC and LC)
Applications
CATV / Video
Passive Optical Network PON
WDM / DWDM
FTTH
Data centres
Supports high speed multi channel video, data and voice services in metropolitan and access networks
ATM, SONET and WDM
