Amphenol Communications Solutions 54601 Series RJ45 Connector Female, Through Hole, Cat3 Unshielded Right Angle 8 Port 8
- RS Stock No.:
- 220-8507
- Mfr. Part No.:
- 54601-908WPLF
- Brand:
- Amphenol Communications Solutions
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 220-8507
- Mfr. Part No.:
- 54601-908WPLF
- Brand:
- Amphenol Communications Solutions
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Amphenol Communications Solutions | |
| Product Type | RJ45 Connector | |
| Ethernet Connector Type | RJ45 | |
| LAN Category | Cat3 | |
| Number of Ports | 8 | |
| Mount Type | Through Hole | |
| Number of Ways | 8 | |
| Connector Gender | Female | |
| Connector Type | Modular Jack | |
| Shield Type | Unshielded | |
| Orientation | Right Angle | |
| Minimum Operating Temperature | -65°C | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | No | |
| Length | 15.24mm | |
| Hazardous Area Certification | NO | |
| Width | 11.5mm | |
| Depth | 18mm | |
| Series | 54601 | |
| Contact Material | Copper Alloy | |
| Contact Plating | Gold | |
| Select all | ||
|---|---|---|
Brand Amphenol Communications Solutions | ||
Product Type RJ45 Connector | ||
Ethernet Connector Type RJ45 | ||
LAN Category Cat3 | ||
Number of Ports 8 | ||
Mount Type Through Hole | ||
Number of Ways 8 | ||
Connector Gender Female | ||
Connector Type Modular Jack | ||
Shield Type Unshielded | ||
Orientation Right Angle | ||
Minimum Operating Temperature -65°C | ||
Termination Type Solder | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals No | ||
Length 15.24mm | ||
Hazardous Area Certification NO | ||
Width 11.5mm | ||
Depth 18mm | ||
Series 54601 | ||
Contact Material Copper Alloy | ||
Contact Plating Gold | ||
RJ45 Jac, 1 x 1 Port 8P8C Cat3 TH
Ethernet Connectors
The Amphenol RJ45 connector having current rating of 2 Amp. It is made up of PA66 material and phosphor bronze contacts.
Durability of 250 cycle
Lead free
