Siemens Emergency Stop Push Button, Panel Mount, SPST, IP67
- RS Stock No.:
- 742-9379
- Mfr. Part No.:
- 3SB3801-2DD3
- Brand:
- Siemens
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£55.22
(exc. VAT)
£66.26
(inc. VAT)
- RS Stock No.:
- 742-9379
- Mfr. Part No.:
- 3SB3801-2DD3
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Mounting Type | Panel Mount | |
| Contact Configuration | SPST | |
| IP Rating | IP67 | |
| Push Button Shape | Round | |
| Depth | 65mm | |
| Width | 85mm | |
| Height | 85mm | |
| Push Button Material | Plastic | |
Select all | ||
|---|---|---|
Brand Siemens | ||
Mounting Type Panel Mount | ||
Contact Configuration SPST | ||
IP Rating IP67 | ||
Push Button Shape Round | ||
Depth 65mm | ||
Width 85mm | ||
Height 85mm | ||
Push Button Material Plastic | ||
- COO (Country of Origin):
- DE
Control Stations with Pushbutton - Metal
The 3SB3 range of enclosures come with standard fittings. These control stations are grey metal and are equipped with actuators and indicators made of metal.
Plastic enclosure with an ingress protection of IP67
Vertical mounting type
Contact blocks for floor mounting (are snapped into the enclosure base)
Cable entry on the top and bottom 1 x M20 each
Mounting diameter 22mm
Vertical mounting type
Contact blocks for floor mounting (are snapped into the enclosure base)
Cable entry on the top and bottom 1 x M20 each
Mounting diameter 22mm
PHASE OUT NOTIFICATION
This product is in obsolescence mode and is due for discontinuation by the manufacturer. We recommend that you review the new pushbutton range SIRIUS ACT which is the alternative range proposed by the manufacturer. Please refer to the 3SB3 / SIRIUS ACT cross-reference guide located in the technical reference section.
