Finder PCB Mount Power Relay, 24V ac Coil, SPDT
- RS Stock No.:
- 894-9427
- Mfr. Part No.:
- 41.61.8.024.0000
- Brand:
- Finder
- RS Stock No.:
- 894-9427
- Mfr. Part No.:
- 41.61.8.024.0000
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Coil Voltage | 24V ac | |
| Contact Configuration | SPDT | |
| Mounting Type | PCB Mount | |
| Number of Poles | 1 | |
| Terminal Type | PCB Pin | |
| Length | 29mm | |
| Maximum Operating Temperature | +70°C | |
| Height | 15.7mm | |
| Minimum Operating Temperature | -40°C | |
| Contact Material | Silver Alloy | |
| Standards Met | cULus, EAC, PCT, RINA, UL, VDE | |
| Series | 41 Series | |
| Depth | 12.6mm | |
| Dimensions | 29 x 12.6 x 15.7mm | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Coil Voltage 24V ac | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Number of Poles 1 | ||
Terminal Type PCB Pin | ||
Length 29mm | ||
Maximum Operating Temperature +70°C | ||
Height 15.7mm | ||
Minimum Operating Temperature -40°C | ||
Contact Material Silver Alloy | ||
Standards Met cULus, EAC, PCT, RINA, UL, VDE | ||
Series 41 Series | ||
Depth 12.6mm | ||
Dimensions 29 x 12.6 x 15.7mm | ||
- COO (Country of Origin):
- IT
41 Series - 41.52, 41.31 & 41.61
PCB mount power relays with ac and dc coils.
Low profile
Flux proof, RTII
Minimum switching load 300mW
8mm creepage and clearance between coil and contacts
Dimensions 15.7x12.5x29 mm
Flux proof, RTII
Minimum switching load 300mW
8mm creepage and clearance between coil and contacts
Dimensions 15.7x12.5x29 mm
Approvals
UL (Canada & US); VDE
