ROHM BR25H128F-5ACE2, 128 kB Serial EEPROM, 3500 μs 8-Pin SOP-8 SPI
- RS Stock No.:
- 266-3801
- Mfr. Part No.:
- BR25H128F-5ACE2
- Brand:
- ROHM
Bulk discount available
Subtotal (1 pack of 10 units)*
£5.66
(exc. VAT)
£6.79
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2,490 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 40 | £0.566 | £5.66 |
| 50 - 90 | £0.555 | £5.55 |
| 100 - 240 | £0.519 | £5.19 |
| 250 - 990 | £0.508 | £5.08 |
| 1000 + | £0.498 | £4.98 |
*price indicative
- RS Stock No.:
- 266-3801
- Mfr. Part No.:
- BR25H128F-5ACE2
- Brand:
- ROHM
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ROHM | |
| Memory Size | 128kB | |
| Product Type | Serial EEPROM | |
| Interface Type | SPI | |
| Package Type | SOP-8 | |
| Mount Type | Surface | |
| Pin Count | 8 | |
| Organisation | 16k x 8 | |
| Maximum Clock Frequency | 20MHz | |
| Minimum Supply Voltage | 1.7V | |
| Maximum Supply Voltage | 5.5V | |
| Number of Bits per Word | 8 | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 125°C | |
| Length | 6.4mm | |
| Height | 1.2mm | |
| Series | BR25H128xxx-5AC | |
| Standards/Approvals | No | |
| Width | 3 mm | |
| Number of Words | 16k | |
| Automotive Standard | AEC-Q100 | |
| Maximum Random Access Time | 3500μs | |
| Supply Current | 1.7mA | |
| Data Retention | 100year | |
| Select all | ||
|---|---|---|
Brand ROHM | ||
Memory Size 128kB | ||
Product Type Serial EEPROM | ||
Interface Type SPI | ||
Package Type SOP-8 | ||
Mount Type Surface | ||
Pin Count 8 | ||
Organisation 16k x 8 | ||
Maximum Clock Frequency 20MHz | ||
Minimum Supply Voltage 1.7V | ||
Maximum Supply Voltage 5.5V | ||
Number of Bits per Word 8 | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 125°C | ||
Length 6.4mm | ||
Height 1.2mm | ||
Series BR25H128xxx-5AC | ||
Standards/Approvals No | ||
Width 3 mm | ||
Number of Words 16k | ||
Automotive Standard AEC-Q100 | ||
Maximum Random Access Time 3500μs | ||
Supply Current 1.7mA | ||
Data Retention 100year | ||
The ROHM EEPROM is a 128Kbit serial of SPI BUS interface, all controls available by 2 ports of serial clock and serial data. 1.7V to 5.5V wide limit of operating voltage, possible 1 MHz operation.
AEC Q100 qualified
HOLD function by the HOLDB pin
