Grayhill Edge Connector, Rack Mount, 48-Contacts, 1-Row, Screw Termination

View all Edge Connectors
Discontinued
RS Stock No.:
878-2766
Mfr. Part No.:
70MRCK24-EC
Brand:
Grayhill
Find similar products by selecting one or more attributes.
Select all

Brand

Grayhill

Body Orientation

Straight

Number of Contacts

48

Number of Rows

1

Mounting Type

Rack Mount

Termination Method

Screw

Keying Way

Yes

Depth

36.8mm

Width

95.3mm

Series Number

70MRCK

Length

341.6mm

RoHS Status: Not Applicable

COO (Country of Origin):
CN

Grayhill 70 Series AC Interface Modules


The 70 series interface modules come in various package sizes making them an ideal option for a number of potential applications and circuits. These include Standard (70-), Mini (70M-), G5 (70G-) and OpenLine (70L-). The G5 and OpenLine modules are equipped with replaceable 5x20mm glass fuses, 5A for G5 and 3.15A for Open Line.
These units feature a built in status LED’s making monitoring much easier. They also offer transient protection and meet the requirements of IEEE472 (Surge Withstanding Capability Test).

Features:
SPST, Normally Open
Zero Crossing Turn-On
Optical isolation
OpenLine® and G5 modules provide replaceable 5x20 mm glass fuses
Built-in status LED
Manufacturers Lifetime Warranty

Standards

IEEE 472, UL, CSA, CE and TUV certified
