- RS Stock No.:
- 384-7032
- Brand:
- RS PRO
47 In stock - FREE next working day delivery available
11 available from Europe for delivery within 1 working day(s).
Added
Price Each
£9.50
(exc. VAT)
£11.40
(inc. VAT)
Units | Per unit |
1 - 14 | £9.50 |
15 - 49 | £9.02 |
50 + | £8.53 |
- RS Stock No.:
- 384-7032
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
High Current Terminals
Fingerproof terminals (to VBG4 requirements)
Flammability rating UL 94-V0
Please note that none of the jumper bars shown in this range are suitable for use with this product
Cable sizes from 6 - 35mm2
Mounting method DIN rail (top hat rail)
Flammability rating UL 94-V0
Please note that none of the jumper bars shown in this range are suitable for use with this product
Cable sizes from 6 - 35mm2
Mounting method DIN rail (top hat rail)
Note
Approvals
UL, CSA
RS PRO 2-Way Earth Terminal Block, Screw-Down, 14 to 4 AWG, 57.5 mm
If you need a versatile, space-saving ground termination for your electrical system that can handle high current and voltage, choose this earth terminal block from RS PRO. It fits American Wire Gauge (AWG) sizes ranging from 14 to 4, making it compatible with a range of applications.
This block is easy to install, as you can simply snap it onto a standard TS 35 DIN rail. The screw clamp termination locks connected wires in place so they won't come loose, even in the event of heavy vibration. This increases workplace safety and reduces maintenance requirements.
The block body is made from flame-retardant nylon, providing additional protection from fire hazards. The green and yellow colour makes the component instantly recognisable as an earth terminal, making safety inspections quick and easy.
This block is easy to install, as you can simply snap it onto a standard TS 35 DIN rail. The screw clamp termination locks connected wires in place so they won't come loose, even in the event of heavy vibration. This increases workplace safety and reduces maintenance requirements.
The block body is made from flame-retardant nylon, providing additional protection from fire hazards. The green and yellow colour makes the component instantly recognisable as an earth terminal, making safety inspections quick and easy.
Features and Benefits
- Cable cross-sectional area (CSA) of 16 mm²
- Green/yellow in colour
- Current rating of 76 A
- Dimensions of 57.5 (length) x 12 (width) x 65 mm (height)
- Nylon housing material
- Two-way
- Screw-down termination method
- Voltage rating of 800 V
- Wire size range of 14 to 4 American Wire Gauge (AWG)
Approvals
UL; CSA
Specifications
Attribute | Value |
---|---|
Wire Size | 14 → 4 AWG |
Cable CSA | 16mm² |
Colour | Green/Yellow |
Number of Ways | 2 |
Termination Method | Screw Down |
Housing Material | Nylon |
Current Rating | 76A |
Voltage Rating | 800 V |
Length | 57.5mm |
Width | 12mm |
Height | 65mm |
