KNITTER-SWITCH 4 Way Surface Mount DIP Switch 4PST, Flat Actuator
- RS Stock No.:
- 918-9916
- Mfr. Part No.:
- DHS 604 J
- Brand:
- KNITTER-SWITCH
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 918-9916
- Mfr. Part No.:
- DHS 604 J
- Brand:
- KNITTER-SWITCH
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KNITTER-SWITCH | |
| Number of Positions | 4 | |
| Mounting Type | Surface Mount | |
| Contact Material | Copper Alloy | |
| Contact Configuration | 4PST | |
| Package Style | DIP | |
| Actuator Type | Flat | |
| Contact Current Rating | 100 (Non-Switching) mA, 25 (Switching) mA | |
| Mechanical Life | 1000Operations | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -40°C | |
| Operating Temperature Range | -40 → +85°C | |
| Voltage Rating | 24 V dc, 50 V dc | |
| Dielectric Strength | 300V ac | |
| Priced to Clear | Yes | |
Select all | ||
|---|---|---|
Brand KNITTER-SWITCH | ||
Number of Positions 4 | ||
Mounting Type Surface Mount | ||
Contact Material Copper Alloy | ||
Contact Configuration 4PST | ||
Package Style DIP | ||
Actuator Type Flat | ||
Contact Current Rating 100 (Non-Switching) mA, 25 (Switching) mA | ||
Mechanical Life 1000Operations | ||
Maximum Operating Temperature +85°C | ||
Minimum Operating Temperature -40°C | ||
Operating Temperature Range -40 → +85°C | ||
Voltage Rating 24 V dc, 50 V dc | ||
Dielectric Strength 300V ac | ||
Priced to Clear Yes | ||
Knitter Switch DHS 6xx Series DIP Switches
The DHS 6xx series has been designed for surface mounting and is available with various contact configurations. The flat actuators are mounted on top of the body and operated with a horizontal sliding motion.
With a wide operating temperature range and a high mechanical life cycle they can be used in a variety of applications. They are sealed with a protective tape making them washable by water or alcohol-based cleaners.
With a wide operating temperature range and a high mechanical life cycle they can be used in a variety of applications. They are sealed with a protective tape making them washable by water or alcohol-based cleaners.
Dual-In-Line Switches
Sub-miniature switches in a choice of configurations and actions. Note that these switches are not suitable for immersion cleaning unless stated otherwise.
