Wurth Elektronik 2 Way Through Hole DIP Switch SPST
- RS Stock No.:
- 254-1776
- Mfr. Part No.:
- 418217270902A
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 tube of 82 units)*
£179.17
(exc. VAT)
£215.004
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 82 unit(s) shipping from 13 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 82 - 82 | £2.185 | £179.17 |
| 164 + | £2.067 | £169.49 |
*price indicative
- RS Stock No.:
- 254-1776
- Mfr. Part No.:
- 418217270902A
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Number of Positions | 2 | |
| Mounting Type | Through Hole | |
| Contact Material | Gold | |
| Contact Configuration | SPST | |
| Actuator Type | Slide | |
| Contact Current Rating | 100 mA | |
Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Number of Positions 2 | ||
Mounting Type Through Hole | ||
Contact Material Gold | ||
Contact Configuration SPST | ||
Actuator Type Slide | ||
Contact Current Rating 100 mA | ||
- COO (Country of Origin):
- TW
The Wurths offers a WS-DITU compact THT right angled with raised actuator made up of PBT material with a contact plating of gold with the operating temperature of -40°C to +85°C and an electrical life with 2000 cycles.
Cover flammability rating of UL94 V-0
Operation force is 800 g
Withstanding voltage is 500 v
Operation force is 800 g
Withstanding voltage is 500 v
