C & K 1 Way Surface Mount DIP Switch SPST, Flush, Recessed, Slide Actuator
- RS Stock No.:
- 161-3044
- Mfr. Part No.:
- TDA01H0SB1R
- Brand:
- C & K
Available to back order for despatch 11/02/2025
Added
Price Each (In a Pack of 5)
£1.862
(exc. VAT)
£2.234
(inc. VAT)
| Units | Per unit | Per Pack* |
| 5 - 20 | £1.862 | £9.31 |
| 25 - 45 | £1.766 | £8.83 |
| 50 - 95 | £1.684 | £8.42 |
| 100 - 195 | £1.596 | £7.98 |
| 200 + | £1.512 | £7.56 |
| *price indicative | ||
- RS Stock No.:
- 161-3044
- Mfr. Part No.:
- TDA01H0SB1R
- Brand:
- C & K
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
C&K’s series of surface mount half-pitch DIP switches, low profile and standard profile DIP switches, rotary and coded DIP switches, coded rotary DIP switches, SIP switches and jumper switches feature a variety of extended actuator and flush actuator styles. C&K DIP switches are available in surface mount, through-hole, right angle and vertical mounting options. Washable DIP Switches for Easier Processing.
Bifurcated contact for increased electrical reliability
Process sealed for surface mount soldering and washable processing
Hand-held electronic devices
Portable computer and electronic devices
Instrumentation and controls
Process sealed for surface mount soldering and washable processing
Hand-held electronic devices
Portable computer and electronic devices
Instrumentation and controls
Specifications
Attribute | Value |
|---|---|
| Number of Positions | 1 |
| Mounting Type | Surface Mount |
| Contact Configuration | SPST |
| Contact Material | Copper Alloy |
| Package Style | DIP |
| Actuator Type | Flush, Recessed, Slide |
| Contact Current Rating | 25 mA @ 24 V dc |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +85°C |
| Voltage Rating | 24V dc |
| Dielectric Strength | 300V ac |
