Weidmuller 1016000000 W Series Brown, 1.5mm², Single-Level, Screw Termination

View all DIN Rail Terminal Blocks

Subtotal (1 unit)*

£9.37

(exc. VAT)

£11.24

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 11 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£9.37

*price indicative

Sponsored
Weidmuller Jumper Bars
Weidmuller Jumper Bars
Weidmuller jumper bars are valued for their reliability, durability, and ease of use in a wide range of electrical applications
Explore Weidmuller Jumper Bars
RS Stock No.:
823-9613
Mfr. Part No.:
1016000000
Brand:
Weidmüller
Find similar products by selecting one or more attributes.
Select all

Brand

Weidmüller

Colour

Brown

Number of Levels

Single

Series

W

Voltage Rating

250 V

American Wire Gauge

26 → 14AWG

Termination Method

Screw

Cable CSA

1.5mm²

Current Rating

10A

Pitch

6.4mm

Minimum Operating Temperature

-50°C

Maximum Operating Temperature

+120°C

WDT/WDTR Test Disconnect Terminal Blocks


WDT/WDTR Series test-disconnect terminals with clamping yoke technology. The terminals are ideal in various applications due to their hardened steel for mechanical strength and high-quality tinned copper for optimum conductivity.

Features and Benefits


• Easy planning and optimised operational safety
• Screw connection
• Snap-on mounting


The ’W’ series screw clamp terminals are suitable for ’Top Hat’ DIN Rail and manufactured from nylon 6.6 which has a continuous temperature rating of 120°C (180°C short term). They are self-extinguishing to UL94V-0 and free from cadmium and halogen. Current bars are constructed from 10 mm electrolytic copper to ensure a current loading more than nominal rating. Terminals are suitable for mounting on symmetric ’Top Hat’ rail only (BS5584:1978, EN 50022) and are touch proof in accordance with BS 3042.
