Phoenix Contact PT 4-TWIN Series Grey Feed Through Terminal Block, 0.2 → 6mm², Single-Level, Push In

50% less insertion force
Compact design and front connection facilitate wiring in the smallest of spaces
Tool-free wiring of conductors with ferrules or solid conductors
Stranded conductors with ferrules can be inserted directly with PIT 2,5 (from 0.34 mm²) and PIT 4 (from 0.5 mm²)
Actuation lever opens the terminal point, so there is no direct contact with live parts
Double bridge shaft enables individual potential distribution and supply

Connect two or more wires or components in your equipment with this feed-through terminal block from Phoenix Contact. You can mount it on a standard DIN rail, so it's compatible with common fixtures makes it easy to achieve secure installation.
The block has three contacts, allowing you to have a separate testing circuit running alongside your main circuitry. It's designed for simple push-in connection with other components, so you can wire them in without any tooling, and remove or rearrange them just as quickly. This reduces maintenance and repair time and makes it easier to adapt or upgrade your electrical system.
This terminal block is made from a grey PA (polyamide) material that offers excellent impact strength and durability, ensuring a long product life. Its high voltage rating of 800V means it's suitable for heavy-duty electrical set-ups.

• Grey in colour
• Single level
• Cable cross-sectional area of 0.2 to 6mm²
• Current rating of 32A
• Voltage rating of 800V
• Wire size of 24 to 10AWG (American Wire Gauge)
• UL (Underwriter Laboratories) 94-V0 rating for flammability means that it will burn for no more than 15 seconds when exposed to a naked flame

Push-In Connection Terminal Blocks

The PT series is characterised by easy, direct conductor connection, and it consistently uses the advantages of the CLIPLINE complete system. The up to 50% lower insertion forces of the PT push-in connection method also allows easy and direct plugging of solid and stranded conductors with ferrules of 0.34mm² and up.
