Siemens 8WH Series Blue Din Rail Terminal, 150mm², 1-Level, Screw Termination, CSA
- RS Stock No.:
- 271-3244
- Mfr. Part No.:
- 8WH1000-0AS01
- Brand:
- Siemens
20 In stock for delivery within 2 working days
Not available for guaranteed pre 9am/10am delivery
Price Each (In a Pack of 10)
£37.55
(exc. VAT)
£45.06
(inc. VAT)
Units | Per unit | Per Pack* |
|---|---|---|
| 10 + | £37.55 | £375.50 |
*price indicative
- RS Stock No.:
- 271-3244
- Mfr. Part No.:
- 8WH1000-0AS01
- Brand:
- Siemens
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- IN
Product Details
The Siemens Terminal Block is a blue colour DIN rail terminal block used for mounting on mounting rail acc. to IEC 60715. This terminal block has 1000 volt operating rated voltage and 309 A operating rated current. The position of the terminal is lateral.
TH35 DIN rail mounting
End cover plate is not required
CSA UR EAC and CE approved
Available with through type terminal
V0 combustibility class according to UL 94
End cover plate is not required
CSA UR EAC and CE approved
Available with through type terminal
V0 combustibility class according to UL 94
Specifications
Attribute | Value |
|---|---|
| Colour | Blue |
| Number of Levels | 1 |
| Series | 8WH |
| American Wire Gauge | 300MCMAWG |
| Termination Method | Screw |
| Cable CSA | 150mm² |
| Fused | No |
| Voltage Rating | 1 kV |
| Hazardous Area Certification | CSA |
