Carlo Gavazzi Switch Mode DIN Rail Power Supply, 340 → 575V ac ac, dc Input, 24V dc dc Output, 5A Output, 120W
- RS Stock No.:
- 857-7454
- Mfr. Part No.:
- SPD241203
- Brand:
- Carlo Gavazzi
Discontinued
- RS Stock No.:
- 857-7454
- Mfr. Part No.:
- SPD241203
- Brand:
- Carlo Gavazzi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Carlo Gavazzi | |
| Type | Switch Mode | |
| Electrical Phase | 3 | |
| Number of Outputs | 1 | |
| AC or DC Input Voltage | ac, dc | |
| Input Voltage | 340 → 575V ac | |
| AC or DC Output Voltage | dc | |
| Output Voltage | 24V dc | |
| Output Current | 5A | |
| Dimensions | 74.3 x 123.6 x 118.8mm | |
| Width | 123.6mm | |
| Height | 123.6mm | |
| Depth | 112mm | |
| Maximum Temperature | +71°C | |
| Mounting Type | DIN Rail Mount | |
| Load Regulation | ±1% | |
| Minimum Temperature | -25°C | |
| Ripple And Noise | 100mV | |
| Select all | ||
|---|---|---|
Brand Carlo Gavazzi | ||
Type Switch Mode | ||
Electrical Phase 3 | ||
Number of Outputs 1 | ||
AC or DC Input Voltage ac, dc | ||
Input Voltage 340 → 575V ac | ||
AC or DC Output Voltage dc | ||
Output Voltage 24V dc | ||
Output Current 5A | ||
Dimensions 74.3 x 123.6 x 118.8mm | ||
Width 123.6mm | ||
Height 123.6mm | ||
Depth 112mm | ||
Maximum Temperature +71°C | ||
Mounting Type DIN Rail Mount | ||
Load Regulation ±1% | ||
Minimum Temperature -25°C | ||
Ripple And Noise 100mV | ||
- COO (Country of Origin):
- CN
Carlo Gavazzi SPD Series Switch Mode Power Supply
SPD series switch mode power supplies provide the user with an Automation-specific designed unit suitable for a comprhensive range of applications. Mounting is made very simple thanks to DIN rail mounting, coupled with a compact construction this Power Supply series can be used in space-restricted applications
Universal AC input range to cover your application
Highly efficient design
Integrated internal filter
LED indication for both DC power ON & DC low
Overload & short circuit protection
Can be mounted onto either 7.5 or 15mm DIN rail
Highly efficient design
Integrated internal filter
LED indication for both DC power ON & DC low
Overload & short circuit protection
Can be mounted onto either 7.5 or 15mm DIN rail
