Carlo Gavazzi SPDE Switched Mode DIN Rail Power Supply 264V ac 48V dc, 1.6 A Output 75 W
- RS Stock No.:
- 263-2963
- Mfr. Part No.:
- SPDE48751
- Brand:
- Carlo Gavazzi
Stock information currently inaccessible
- RS Stock No.:
- 263-2963
- Mfr. Part No.:
- SPDE48751
- Brand:
- Carlo Gavazzi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Carlo Gavazzi | |
| Series | SPDE | |
| Product Type | DIN Rail Power Supply | |
| Sub Type | Switched Mode | |
| Maximum Output Voltage | 48V dc | |
| Electrical Phase | 1 | |
| Power | 75W | |
| Output Current | 1.6A | |
| IP Rating | IP20 | |
| Remote signal DC-OK | Yes | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 70°C | |
| Depth | 87.5mm | |
| Width | 32mm | |
| Standards/Approvals | UL/EN62368-1, UL61010-2-201, UL61010-11, UL61010-1, EN62368-11 | |
| Height | 125mm | |
| Hazardous Area Certification | No | |
| Maximum Input Voltage | 264V ac | |
| Minimum Input Voltage | 90V ac | |
| Efficiency | 94% | |
| Select all | ||
|---|---|---|
Brand Carlo Gavazzi | ||
Series SPDE | ||
Product Type DIN Rail Power Supply | ||
Sub Type Switched Mode | ||
Maximum Output Voltage 48V dc | ||
Electrical Phase 1 | ||
Power 75W | ||
Output Current 1.6A | ||
IP Rating IP20 | ||
Remote signal DC-OK Yes | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 70°C | ||
Depth 87.5mm | ||
Width 32mm | ||
Standards/Approvals UL/EN62368-1, UL61010-2-201, UL61010-11, UL61010-1, EN62368-11 | ||
Height 125mm | ||
Hazardous Area Certification No | ||
Maximum Input Voltage 264V ac | ||
Minimum Input Voltage 90V ac | ||
Efficiency 94% | ||
- COO (Country of Origin):
- CN
The Carlo Gavazzi DIN-rail mount power supplies encompasses high performance within an extremely
compact footprint.
High efficiency
Flexible installation
Integrated protection
