Weidmüller PRO Max Switched Mode Power Supply DIN Rail Power Supply 277V ac/dc AC/DC Input 48V dc, 20 A Output DC 960 W
- RS Stock No.:
- 303-120
- Mfr. Part No.:
- 1478270000
- Brand:
- Weidmüller
Subtotal (1 unit)*
£594.81
(exc. VAT)
£713.77
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 1 unit(s) ready to ship from another location
- Plus 1 unit(s) shipping from 24 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £594.81 |
*price indicative
- RS Stock No.:
- 303-120
- Mfr. Part No.:
- 1478270000
- Brand:
- Weidmüller
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Weidmüller | |
| Product Type | DIN Rail Power Supply | |
| Series | PRO Max | |
| Maximum Output Voltage | 48V dc | |
| Sub Type | Switched Mode Power Supply | |
| Electrical Phase | 1 | |
| Input Voltage Type | AC/DC | |
| Number of Outputs | 1 | |
| Power | 960W | |
| Output Current | 20A | |
| IP Rating | IP20 | |
| Output Voltage Type | DC | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 70°C | |
| Depth | 150mm | |
| Standards/Approvals | -3, -4, -5, -6, -8, E255651EN 55024, EN 55032, IEC61000-3-2, IEC61000-4-2, -11 | |
| Hazardous Area Certification | No | |
| Height | 130mm | |
| Width | 140mm | |
| Maximum Input Voltage | 277V ac/dc | |
| Efficiency | 94% | |
| Minimum Input Voltage | 80V | |
| Select all | ||
|---|---|---|
Brand Weidmüller | ||
Product Type DIN Rail Power Supply | ||
Series PRO Max | ||
Maximum Output Voltage 48V dc | ||
Sub Type Switched Mode Power Supply | ||
Electrical Phase 1 | ||
Input Voltage Type AC/DC | ||
Number of Outputs 1 | ||
Power 960W | ||
Output Current 20A | ||
IP Rating IP20 | ||
Output Voltage Type DC | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 70°C | ||
Depth 150mm | ||
Standards/Approvals -3, -4, -5, -6, -8, E255651EN 55024, EN 55032, IEC61000-3-2, IEC61000-4-2, -11 | ||
Hazardous Area Certification No | ||
Height 130mm | ||
Width 140mm | ||
Maximum Input Voltage 277V ac/dc | ||
Efficiency 94% | ||
Minimum Input Voltage 80V | ||
- COO (Country of Origin):
- CN
The Weidmüller PROmax Switch mode power supply offers diverse solutions for demanding automation. This high performance and durable PROmax switch modepower supply units are designed for especially demanding requirements. PROmax reliably copes with continuous overload of up to 20% or short term peak loads of 300% occurring with high control cabinet temperatures.
High boost capability
Protection against inverse voltage
Input fuse included
Surge protection by varistor
