Lumberg, 332 5 Pole Straight M16 DIN Plug, DIN EN 60529, 5A, 250 V ac IP68, Threaded, Cable Male

RS Stock No.:: 170-5569
Mfr. Part No.:: 0332 05-1
Brand:: Lumberg

Lumberg, 332 5 Pole Straight M16 DIN Plug, DIN EN 60529, 5A, 250 V ac IP68, Threaded, Cable Male

Subtotal (1 box of 50 units)*

£389.45

(exc. VAT)

£467.35

(inc. VAT)

FREE delivery for orders over £50.00

Temporarily out of stock

350 unit(s) shipping from 26 March 2026
Plus 150 unit(s) shipping from 20 May 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Per Box*
50 +	£7.789	£389.45

*price indicative

RS Stock No.:: 170-5569
Mfr. Part No.:: 0332 05-1
Brand:: Lumberg

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Lumberg
	Product Type	DIN Plug
	Number of Contacts	5
	Mount Type	Cable
	Current	5A
	Connector Size	M16
	Connector Gender	Male
	Mating Type	Threaded
	Shield Type	Shielded
	Orientation	Straight
	Voltage	250 V ac
	IP Rating	IP68
	Termination Type	Solder
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	85°C
	DIN Number	DIN EN 60529
	Contact Gender	Male
	Series	332
	Standards/Approvals	No
	Housing Material	Copper Zinc Alloy
	Pole Format	5
	Contact Plating	Gold over Silver
	Contact Material	Brass

	Select all
	Brand Lumberg
	Product Type DIN Plug
	Number of Contacts 5
	Mount Type Cable
	Current 5A
	Connector Size M16
	Connector Gender Male
	Mating Type Threaded
	Shield Type Shielded
	Orientation Straight
	Voltage 250 V ac
	IP Rating IP68
	Termination Type Solder
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 85°C
	DIN Number DIN EN 60529
	Contact Gender Male
	Series 332
	Standards/Approvals No
	Housing Material Copper Zinc Alloy
	Pole Format 5
	Contact Plating Gold over Silver
	Contact Material Brass

0332 Circular connectors with threaded joint Datasheet

Lumberg DIN Plug

The Lumberg DIN plug is a 5-pole, male, cable mount connector with an electric rating of 250VAC and 5A. It is round in shape with pins arranged in a circular pattern within the connector. It has chassis, cable mount plugs and sockets up to 12-way. The body of connector is MADE from zinc alloy material with brass contacts and silver or gold finish. This circular connector socket is designed to be mounted on printed circuit boards and is also suitable for locking.

Lumberg Connectors Standard and SWUM™ - IP68

Lumberg Connectors Standard and SWUM™ - IP68 Chassis and cable mount plugs and sockets up to 12-way, with or without 360° shielding.

Features and Benefits

360° shielded design

Long bend protection

Operating temperature ranging between -40°C and 85°C

Screw on mating type

Solder terminals

Straight orientation with a threaded joint

Applications

Automation technology

Control engineering

Medical instrumentation

MIDI instruments

PC keyboards

Portable video devices and projectors

Certifications

IEC60130-9

IP68 rated
