Microchip, DAC Dual 12 bit- Parallel & Serial (SPI), 10-Pin DFN, MSOP, QFN
- RS Stock No.:
- 203-4735
- Mfr. Part No.:
- MCP48CVB22-E/MF
- Brand:
- Microchip
Subtotal (1 tube of 120 units)*
£176.76
(exc. VAT)
£212.16
(inc. VAT)
FREE delivery for orders over £50.00
Being discontinued
- Final 120 unit(s), ready to ship
Units | Per unit | Per Tube* |
|---|---|---|
| 120 + | £1.473 | £176.76 |
*price indicative
- RS Stock No.:
- 203-4735
- Mfr. Part No.:
- MCP48CVB22-E/MF
- Brand:
- Microchip
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Microchip | |
| Resolution | 12 bit | |
| Number of DAC Channels | 2 | |
| Mounting Type | Surface Mount | |
| Package Type | DFN, MSOP, QFN | |
| Pin Count | 10 | |
| Digital Interface Type | Parallel & Serial (SPI) | |
Select all | ||
|---|---|---|
Brand Microchip | ||
Resolution 12 bit | ||
Number of DAC Channels 2 | ||
Mounting Type Surface Mount | ||
Package Type DFN, MSOP, QFN | ||
Pin Count 10 | ||
Digital Interface Type Parallel & Serial (SPI) | ||
The Microchip Technology MCP48CXBXX are single and dual-channel 8-bit, 10-bit, and 12-bit buffered voltage output Digital to Analog Converters, with volatile or MTP memory and an SPI serial interface. The MTP memory can be written by the user up to 32 times, for each specific register.
Power-on or G10brown-out Reset Protection
-40°C to +125°C extended temperature range
1 LSb Integral Nonlinearity (INL) Specification
-40°C to +125°C extended temperature range
1 LSb Integral Nonlinearity (INL) Specification
