SEGGER 8.06.20 RL78 14-pin Programming Adapter for use with J-Link 20-Pin 0.1 in Target Connector to Renesas 14-Pin E1
- RS Stock No.:
- 146-4387
- Mfr. Part No.:
- 8.06.20 RL78 14-pin Programming Adapter
- Brand:
- SEGGER
Save 8% when you buy 10 units
Subtotal (1 unit)*
£55.25
(exc. VAT)
£66.30
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 24 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £55.25 |
5 - 9 | £52.49 |
10 + | £50.83 |
*price indicative
- RS Stock No.:
- 146-4387
- Mfr. Part No.:
- 8.06.20 RL78 14-pin Programming Adapter
- Brand:
- SEGGER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | SEGGER | |
For Use With | J-Link 20-Pin 0.1 in Target Connector to Renesas 14-Pin E1 Connector | |
Select all | ||
---|---|---|
Brand SEGGER | ||
For Use With J-Link 20-Pin 0.1 in Target Connector to Renesas 14-Pin E1 Connector | ||
The Flasher RL78 Adapter converts the standard J-Link 20-pin 0.1" connector to the standard 14-pin E1 connector defined by Renesas. Please note that this adapter is usable only with the Flasher PRO and the Flasher Portable PLUS and only for the purpose of flash programming. It cannot be used with a J-Link and it cannot be used for debugging RL78 devices.The TOOL0 pins of the RL78 devices are open drain and require an external pull-up resistor. This resistor is usually placed on the evaluation board, nevertheless the adapter has an additional solder bridge between VTREF and TOOL0 to place the pull-up resistor.
