TRACOPOWER TDN 3WI DC-DC Converter, ±12V dc/ ±125mA Output, 4.5 → 18 V dc Input, 3W, Through Hole, +70°C Max
- RS Stock No.:
- 899-8242
- Mfr. Part No.:
- TDN 3-1222WI
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£18.44
(exc. VAT)
£22.13
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 11 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £18.44 |
| 5 - 9 | £17.91 |
| 10 - 24 | £17.33 |
| 25 - 49 | £16.60 |
| 50 + | £15.86 |
*price indicative
- RS Stock No.:
- 899-8242
- Mfr. Part No.:
- TDN 3-1222WI
- Brand:
- TRACOPOWER
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | ±12V dc | |
| Input Voltage Range | 4.5 → 18 V dc | |
| Power Rating | 3W | |
| Input Voltage Nominal | 12 V dc | |
| Output Current | ±125mA | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 2 | |
| Output Voltage Adjustment Range | ±11.88 V dc, ±12.12V dc | |
| Package | DIP | |
| Isolation Voltage | 1.5kV dc | |
| Width | 9.1mm | |
| Depth | 10.2mm | |
| Length | 13.2mm | |
| Series | TDN 3WI | |
| Load Regulation | 0.01 | |
| Efficiency | 82% | |
| Maximum Temperature | +70°C | |
| Standards Met | EN 55022, EN 60950-1, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, IEC 60950-1, REACH, RoHS Compliant, UL 60950-1 | |
| Minimum Temperature | -40°C | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage ±12V dc | ||
Input Voltage Range 4.5 → 18 V dc | ||
Power Rating 3W | ||
Input Voltage Nominal 12 V dc | ||
Output Current ±125mA | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 2 | ||
Output Voltage Adjustment Range ±11.88 V dc, ±12.12V dc | ||
Package DIP | ||
Isolation Voltage 1.5kV dc | ||
Width 9.1mm | ||
Depth 10.2mm | ||
Length 13.2mm | ||
Series TDN 3WI | ||
Load Regulation 0.01 | ||
Efficiency 82% | ||
Maximum Temperature +70°C | ||
Standards Met EN 55022, EN 60950-1, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, IEC 60950-1, REACH, RoHS Compliant, UL 60950-1 | ||
Minimum Temperature -40°C | ||
