TRACOPOWER THL 25WI DC-DC Converter, 12V dc/ 2.09A Output, 18 → 75 V dc Input, 25W, Through Hole, +80°C Max Temp
- RS Stock No.:
- 817-9101
- Mfr. Part No.:
- THL 25-4812WI
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£51.39
(exc. VAT)
£61.67
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- Final 9 unit(s), ready to ship from another location
Units | Per unit |
|---|---|
| 1 - 4 | £51.39 |
| 5 - 9 | £49.84 |
| 10 - 24 | £48.31 |
| 25 - 49 | £46.25 |
| 50 + | £44.20 |
*price indicative
Alternative
This product is not currently available. Here is our alternative recommendation.
1 Tube of 10
£537.78
(exc. VAT)
£645.34
(inc. VAT)
- RS Stock No.:
- 817-9101
- Mfr. Part No.:
- THL 25-4812WI
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | 12V dc | |
| Input Voltage Range | 18 → 75 V dc | |
| Power Rating | 25W | |
| Input Voltage Nominal | 48 V dc | |
| Output Current | 2.09A | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Isolation Voltage | 1.5kV dc | |
| Depth | 10.2mm | |
| Length | 25.4mm | |
| Series | THL 25WI | |
| Load Regulation | 0.002 | |
| Efficiency | 90% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +80°C | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 12V dc | ||
Input Voltage Range 18 → 75 V dc | ||
Power Rating 25W | ||
Input Voltage Nominal 48 V dc | ||
Output Current 2.09A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Isolation Voltage 1.5kV dc | ||
Depth 10.2mm | ||
Length 25.4mm | ||
Series THL 25WI | ||
Load Regulation 0.002 | ||
Efficiency 90% | ||
Minimum Temperature -40°C | ||
Maximum Temperature +80°C | ||
- COO (Country of Origin):
- TW
Traco 25W Single/Dual Output Regulated Isolated DC-DC Converter - THL 25WI Series
The Tracopower THL 25WI comes in a metal case of very small dimensions, with high efficiency of up to 90% this isolated DC/DC converter is suited for use in temperature ranges of up to +80°C, or +85°C with optional mounted heat sink. The THL 25WI range of DC/DC converters feature a wide 4:1 input voltage range and precisely regulated output voltages. Typical applications of these DC/DC converters are in mobile equipments, instrumentation, distributes power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.
Highest power density 25W converter
Ultra compact design
Shielded metal case with isolated baseplate
Wide 4:1 input voltage ranges
Very high efficiency up to 90%
Output voltage adjustable
Remote On/Off control
Operating temperature range –40°C up to +80°C, +85°C with heat-sink
I/O isolation voltage 1500 VDC
Ultra compact design
Shielded metal case with isolated baseplate
Wide 4:1 input voltage ranges
Very high efficiency up to 90%
Output voltage adjustable
Remote On/Off control
Operating temperature range –40°C up to +80°C, +85°C with heat-sink
I/O isolation voltage 1500 VDC
Standards
UL/cUL 60950-1
IEC/EN 60950-1
IEC/EN 60950-1
