TRACOPOWER TMR 3HI DC-DC Converter, 3.3V dc/ 700mA Output, 9 → 18 V dc Input, 3W, Through Hole, +85°C Max Temp

RS Stock No.:: 770-2090
Mfr. Part No.:: TMR 3-1210HI
Brand:: TRACOPOWER

TRACOPOWER TMR 3HI DC-DC Converter, 3.3V dc/ 700mA Output, 9 → 18 V dc Input, 3W, Through Hole, +85°C Max Temp

Available to back order for despatch 03/12/2024

Price Each

£11.58

(exc. VAT)

£13.90

(inc. VAT)

Units	Per unit
1 +	£11.58

RS Stock No.:: 770-2090
Mfr. Part No.:: TMR 3-1210HI
Brand:: TRACOPOWER

Technical Reference

Legislation and Compliance

COO (Country of Origin):: TW

Product Details

Traco 3W SIP Single/Dual Output Regulated Isolated DC-DC Converter - TMR 3HI Series

The TMR 3HI series is a family of 3W single/dual output DC/DC converters with a compact SIP-8 package, regulated output and a wide 2:1 input voltage range. These Traco Power 3W single/dual output DC/DC converters are highly efficient allowing a -40 to +85°C operating temperature range. The compact size of these single/dual output DC/DC converters make them ideal for use in applications such as communication equipment, instrumentation and industrial electronics.

Wide 2:1 input voltage range
Regulated outputs
1500 and 3000 V input / output isolation
Remote On/Off Control
Continuous short circuit protection
UL94V-0 package material
SIP-8 package

Standards

IEC/EN 60950-1, UL 60950-1

Approvals

UL/cUL

Specifications

Attribute	Value
Output Voltage	3.3V dc
Input Voltage Range	9 → 18 V dc
Power Rating	3W
Input Voltage Nominal	12 V dc
Output Current	700mA
Mounting Type	Through Hole
Isolated	Yes
Number of Outputs	1
Package	SIP 8
Isolation Voltage	3kV dc
Length	21.8mm
Depth	11.1mm
Series	TMR 3HI
Load Regulation	0.01
Minimum Temperature	-40°C
Maximum Temperature	+85°C
Efficiency	77%
