TRACOPOWER TMR 3WIE DC-DC Converter, 3.3V dc/ 700mA Output, 18 → 75 V dc Input, 3W, Through Hole, +85°C Max Temp
- RS Stock No.:
- 770-2037
- Mfr. Part No.:
- TMR 3-4810WIE
- Brand:
- TRACOPOWER
18 In stock - FREE next working day delivery available
Added
Price Each
£14.43
(exc. VAT)
£17.32
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £14.43 |
| 5 - 9 | £14.00 |
| 10 - 24 | £13.56 |
| 25 - 49 | £12.99 |
| 50 + | £12.41 |
- RS Stock No.:
- 770-2037
- Mfr. Part No.:
- TMR 3-4810WIE
- Brand:
- TRACOPOWER
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
Traco 3W SIP Single/Dual Output Regulated Isolated DC-DC Converter - TMR 3WIE Series
The TMR-3WIE series is a family of 3W single/dual output DC/DC converters with a compact SIP-8 package, regulated output and a wide 4:1 input voltage range. These Traco Power 3W single/dual output DC/DC converters are highly efficient allowing a -40 to +85°C operating temperature range. The compact size of these single/dual output DC/DC converters make them ideal for use in applications such as communication equipment, instrumentation and industrial electronics.
Wide 4:1 input voltage range
Compact SIP_8 package
Cost optimized design
Temperature range -40℃ to + 85℃
I/O isolation 1600 VDC
Remote On/Off control
3 year product warranty
Compact SIP_8 package
Cost optimized design
Temperature range -40℃ to + 85℃
I/O isolation 1600 VDC
Remote On/Off control
3 year product warranty
Standards
UL/cUL 60950-1, EN 60950-1, IEC 60950-1
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 3.3V dc |
| Input Voltage Range | 18 → 75 V dc |
| Power Rating | 3W |
| Input Voltage Nominal | 48 V dc |
| Output Current | 700mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | SIP 8 |
| Isolation Voltage | 1.5kV dc |
| Depth | 11.2mm |
| Length | 21.8mm |
| Series | TMR 3WIE |
| Load Regulation | 0.01 |
| Maximum Temperature | +85°C |
| Minimum Temperature | -40°C |
| Efficiency | 74% |
