MEAN WELL DC-DC Converter, 24V dc/ 625mA Output, 9.2 → 18 V dc Input, 15W, Chassis Mount, +60°C Max Temp -10°C
- RS Stock No.:
- 678-3540
- Distrelec Article No.:
- 169-26-146
- Mfr. Part No.:
- SD-15A-24
- Brand:
- MEAN WELL
Save 15% when you buy 50 units
Subtotal (1 unit)*
£17.27
(exc. VAT)
£20.72
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 94 unit(s) ready to ship
- Plus 2 unit(s) shipping from 09 December 2025
- Plus 180 unit(s) shipping from 09 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £17.27 |
| 5 - 9 | £16.84 |
| 10 - 24 | £16.41 |
| 25 - 49 | £15.98 |
| 50 + | £14.67 |
*price indicative
- RS Stock No.:
- 678-3540
- Distrelec Article No.:
- 169-26-146
- Mfr. Part No.:
- SD-15A-24
- Brand:
- MEAN WELL
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Output Voltage | 24V dc | |
| Input Voltage Range | 9.2 → 18 V dc | |
| Power Rating | 15W | |
| Input Voltage Nominal | 12 V dc | |
| Output Current | 625mA | |
| Mounting Type | Chassis Mount | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | 21.6 → 26.4V | |
| Isolation Voltage | 2kV ac | |
| Length | 78mm | |
| Depth | 28mm | |
| Width | 51mm | |
| Load Regulation | ±0.2% | |
| Maximum Temperature | +60°C | |
| Standards Met | 3, 4, 5, 6, 8, EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A | |
| Efficiency | 70% | |
| Minimum Temperature | -10°C | |
Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Output Voltage 24V dc | ||
Input Voltage Range 9.2 → 18 V dc | ||
Power Rating 15W | ||
Input Voltage Nominal 12 V dc | ||
Output Current 625mA | ||
Mounting Type Chassis Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range 21.6 → 26.4V | ||
Isolation Voltage 2kV ac | ||
Length 78mm | ||
Depth 28mm | ||
Width 51mm | ||
Load Regulation ±0.2% | ||
Maximum Temperature +60°C | ||
Standards Met 3, 4, 5, 6, 8, EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A | ||
Efficiency 70% | ||
Minimum Temperature -10°C | ||
