TDK-Lambda PXG-M DC/DC Converter, 5V/ 3 A, 36V dc Input, 9V Input 20 W, Surface, 105 °C Max Temp -40 °C Min Temp, 6-Pin
- RS Stock No.:
- 283-1822
- Distrelec Article No.:
- 302-39-391
- Mfr. Part No.:
- PXG-M20-24WD12
- Brand:
- TDK-Lambda
Subtotal (1 unit)*
£78.77
(exc. VAT)
£94.52
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 07 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £78.77 |
*price indicative
- RS Stock No.:
- 283-1822
- Distrelec Article No.:
- 302-39-391
- Mfr. Part No.:
- PXG-M20-24WD12
- Brand:
- TDK-Lambda
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK-Lambda | |
| Output Voltage 1 | 5V | |
| Product Type | DC/DC Converter | |
| Maximum Input Voltage | 36V dc | |
| Minimum Input Voltage | 9V | |
| Output Current 1 | 3A | |
| Output Current 2 | 4A | |
| Mount Type | Surface | |
| Output Voltage 2 | 24V dc | |
| Input Ratio | 4:1 | |
| Number of Outputs | 2 | |
| MTBF | 2080000h | |
| Ripple and Noise | 50mV | |
| Output Voltage Adjustment Range | 4.5/28.8 V | |
| Isolation Voltage | 5kV | |
| Number of Pins | 6 | |
| Maximum Output Power | 20W | |
| Series | PXG-M | |
| Standards/Approvals | IEC 62368-1, IEC 60601-1 | |
| Width | 1in | |
| Length | 1.6in | |
| Weight | 24g | |
| Maximum Operating Temperature | 105°C | |
| Efficiency | 88% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand TDK-Lambda | ||
Output Voltage 1 5V | ||
Product Type DC/DC Converter | ||
Maximum Input Voltage 36V dc | ||
Minimum Input Voltage 9V | ||
Output Current 1 3A | ||
Output Current 2 4A | ||
Mount Type Surface | ||
Output Voltage 2 24V dc | ||
Input Ratio 4:1 | ||
Number of Outputs 2 | ||
MTBF 2080000h | ||
Ripple and Noise 50mV | ||
Output Voltage Adjustment Range 4.5/28.8 V | ||
Isolation Voltage 5kV | ||
Number of Pins 6 | ||
Maximum Output Power 20W | ||
Series PXG-M | ||
Standards/Approvals IEC 62368-1, IEC 60601-1 | ||
Width 1in | ||
Length 1.6in | ||
Weight 24g | ||
Maximum Operating Temperature 105°C | ||
Efficiency 88% | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- TW
The TDK-Lambda is a 15 to 20W Medical and Industrial DC-DC Converters. The PXG-M series of medical and industrial DC-DC converters feature a wide 4:1 input range in a compact 1.6 x 1 inch industry standard package. With 5kV input to output isolation, 2.5uA touch current and a low off-load power draw, these encapsulated modules are ideal for fixed and portable applications.
Less Board Area Needed
Suitable For Medical and Industrial Applications
High Input to Output Isolation
Longer Battery Life
