TDK-Lambda CCG 1.3-10W DC-DC Converter, 3.3V dc/ 2.6A Output, 9 → 36 V dc Input, 8.58W, Through Hole, +100°C Max

The TDK-Lambda is a 1.3 to 10.8W DC-DC Converter. The space saving CCG1R5 to CCG10 series of isolated DC-DC converters operate from wide range 4.5 to 18V, 9 to 36Vdc or 18 to 76V inputs with 1.3W to 10.8W power levels and output voltages from 3.3V to 30V (1). Single output models can be adjusted -5% to +10% by using the trim terminal. The CCG can operate in ambient temperatures of up to -40 to +100°C (model dependent) and have an input to output isolation of 1,500Vdc. Both through hole and surface mount packages are offered.

Wide 4:1 Input Ranges
Space Saving Package Sizes
Reduced Derating at High Ambient Temperatures
No Silicone Potting
Less Board Area Needed
Easier System Compliance
More Useable Power
Reduced Quality Risk During Surface Mount Reflow Process
