TRACOPOWER TMR 12WI DC-DC Converter, 5V dc/ 1.2A Output, 9 → 36 V dc Input, 12W, PCB Mount, +85°C Max Temp -40°C
- RS Stock No.:
- 251-7287
- Mfr. Part No.:
- TMR 12-2421WI
- Brand:
- TRACOPOWER
Available to back order for despatch when stock is available
Price Each (In a Tube of 10)
£317.89
(exc. VAT)
£381.47
(inc. VAT)
Units | Per unit | Per Tube* |
---|---|---|
1 - 4 | £317.89 | £3,178.90 |
5 - 9 | £308.35 | £3,083.50 |
10 - 24 | £298.82 | £2,988.20 |
25 - 49 | £286.10 | £2,861.00 |
50 + | £273.39 | £2,733.90 |
*price indicative
- RS Stock No.:
- 251-7287
- Mfr. Part No.:
- TMR 12-2421WI
- Brand:
- TRACOPOWER
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- TW
Product Details
TRACOPOWER TMR 12WI Series DC-DC Converter, 86 % Efficiency, 9 to 36 V DC Input Voltage Range - TMR 12-2421WI
This DC-DC converter from TRACOPOWER is a compact 12 Watt converter in SIP-8 metal casing, offering an ultra-high power density of 4.73W/cm³. With wide 4:1 input voltage ranges and a very high efficiency of up to 90%, this converter is an ideal solution for various applications in communication equipment, instrumentation, and industrial electronics.
Features & Benefits
• Ultra-compact 12 Watt converter
• Highest power density of 4.73W/cm³
• Wide 4:1 input voltage ranges
• Very high efficiency of up to 90% for energy saving
• Regulated outputs with remote On/Off control
• Continuous short circuit protection
• Highest power density of 4.73W/cm³
• Wide 4:1 input voltage ranges
• Very high efficiency of up to 90% for energy saving
• Regulated outputs with remote On/Off control
• Continuous short circuit protection
Applications
• Communication equipment
• Suitable for mobile and stationary railway applications
• Suitable for mobile and stationary railway applications
Can it operate in extreme temperatures?
This DC-DC converter has an operating temperature range of -40°C to +85°C, making it suitable for harsh environments.
Will it work with various input voltages?
Yes, with wide input voltage ranges from 9 to 36 VDC, this converter is versatile for different applications.
Is it suitable for space-critical applications?
Yes, with its very compact dimensions and high power density, it is an ideal solution for applications with limited space.
Specifications
Attribute | Value |
---|---|
Output Voltage | 5V dc |
Input Voltage Range | 9 → 36 V dc |
Power Rating | 12W |
Input Voltage Nominal | 24 V DC |
Output Current | 1.2A |
Mounting Type | PCB Mount |
Isolated | Yes |
Number of Outputs | 2 |
Output Voltage Adjustment Range | -5 → +5V dc |
Package | SIP 8 |
Isolation Voltage | 1.6kV dc |
Width | 9.6mm |
Depth | 12mm |
Length | 22mm |
Railway Approved | No |
Series | TMR 12WI |
Load Regulation | 1% |
Minimum Temperature | -40°C |
Standards Met | RoHS |
Efficiency | 86% |
Maximum Temperature | +85°C |
Medical Approved | No |
