TRACOPOWER THR 20WI Isolated DC-DC Converter, 12V dc/ 833 mA, 36V dc Input, 9V Input 10 W, PCB, 85 °C Max Temp -40 °C
- RS Stock No.:
- 249-5476
- Distrelec Article No.:
- 302-64-380
- Mfr. Part No.:
- THR 20-2422WI
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£49.42
(exc. VAT)
£59.30
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 4 | £49.42 |
| 5 - 9 | £47.94 |
| 10 - 24 | £46.46 |
| 25 - 49 | £44.49 |
| 50 + | £42.51 |
*price indicative
- RS Stock No.:
- 249-5476
- Distrelec Article No.:
- 302-64-380
- Mfr. Part No.:
- THR 20-2422WI
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage 1 | 12V dc | |
| Product Type | Isolated DC-DC Converter | |
| Maximum Input Voltage | 36V dc | |
| Minimum Input Voltage | 9V | |
| Output Current 1 | 833mA | |
| Output Current 2 | -833mA | |
| Output Voltage 2 | 12V dc | |
| Mount Type | PCB | |
| Input Ratio | 4:1 | |
| Number of Outputs | 2 | |
| MTBF | 665000h | |
| Output Voltage Adjustment Range | ±10 % | |
| Isolation Voltage | 3kV dc | |
| Number of Pins | 6 | |
| Maximum Output Power | 10W | |
| Package Type | 2 x 1 in | |
| Depth | 11mm | |
| Length | 50.8mm | |
| Width | 25.4mm | |
| Standards/Approvals | No | |
| Series | THR 20WI | |
| Efficiency | 86% | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 1 12V dc | ||
Product Type Isolated DC-DC Converter | ||
Maximum Input Voltage 36V dc | ||
Minimum Input Voltage 9V | ||
Output Current 1 833mA | ||
Output Current 2 -833mA | ||
Output Voltage 2 12V dc | ||
Mount Type PCB | ||
Input Ratio 4:1 | ||
Number of Outputs 2 | ||
MTBF 665000h | ||
Output Voltage Adjustment Range ±10 % | ||
Isolation Voltage 3kV dc | ||
Number of Pins 6 | ||
Maximum Output Power 10W | ||
Package Type 2 x 1 in | ||
Depth 11mm | ||
Length 50.8mm | ||
Width 25.4mm | ||
Standards/Approvals No | ||
Series THR 20WI | ||
Efficiency 86% | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
RoHS Status: Exempt
- COO (Country of Origin):
- TW
TRACOPOWER THR 20WI Series Isolated DC-DC Converter, 9 to 36V DC Input Voltage Range, 20W - THR 20-2422WI
This isolated DC-DC converter features a compact PCB mount design with 50.8mm x 25.4mm x 11mm dimensions and converts input voltages from 9V to 36V DC to a stable 12V DC output. With a 20W power rating and 833 mA output current, it is ideal for industrial and electronic systems needing reliable voltage regulation.
Features & Benefits
• Reinforced isolation up to 3000V AC for enhanced safety
• 86% efficiency minimises energy loss
• Adjustable output voltage by ±10% for flexibility
• Dual output option available for complex circuits
Applications
• Ideal for railway control systems
• Can be used with measurement instrumentation components
Can it operate in extreme temperatures?
Yes, it functions between -40°C and +80°C.
Is it suitable for sensitive applications?
Yes, it meets relevant EN and IEC safety standards.
