TRACOPOWER TMR DC-DC Converter, 12V dc/ 333mA Output, 18 → 75 V dc Input, 4W, Through Hole, +85°C Max Temp -40°C
- RS Stock No.:
- 209-9836
- Mfr. Part No.:
- TMR 4-4812WI
- Brand:
- TRACOPOWER
Available to back order for despatch 16/10/2024
Price Each
£13.11
(exc. VAT)
£15.73
(inc. VAT)
Units | Per unit |
---|---|
1 - 4 | £13.11 |
5 - 9 | £12.72 |
10 - 24 | £12.32 |
25 - 49 | £11.80 |
50 + | £11.27 |
- RS Stock No.:
- 209-9836
- Mfr. Part No.:
- TMR 4-4812WI
- Brand:
- TRACOPOWER
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- TW
Product Details
The TRACOPOWER TMR 4WI is a regulated 4 Watt DC/DC converter series with 4:1 input voltage range. It comes in a compact SIP-8 package featuring single and dual output models, I/O isolation voltage of 1600 VDC and protection against short-circuit and over load. Being a 4 Watt converter this series acts as an excellent gap closer between the more common 3 & 6 Watt converters. It offers a cost-efficient alternative to 5 and 6 Watt converters in applications where a 3 Watt converter would operate at the absolute technical limits (e.g. output power).
Compact SIP-8 package
Wide 4:1 input voltage range
Temperature range –40° to +70°C without derating
High efficiency up to 83%
I/O isolation 1600 VDC
Protection against short-circuit and over load
Fully regulated outputs
Remote On/Off control
3-year product warranty
Wide 4:1 input voltage range
Temperature range –40° to +70°C without derating
High efficiency up to 83%
I/O isolation 1600 VDC
Protection against short-circuit and over load
Fully regulated outputs
Remote On/Off control
3-year product warranty
Specifications
Attribute | Value |
---|---|
Output Voltage | 12V dc |
Input Voltage Range | 18 → 75 V dc |
Power Rating | 4W |
Input Voltage Nominal | 48 V dc |
Output Current | 333mA |
Mounting Type | Through Hole |
Isolated | Yes |
Number of Outputs | 1 |
Output Voltage Adjustment Range | 12V dc |
Package | SIP 8 |
Isolation Voltage | 1.6kV |
Length | 21.8mm |
Width | 9.3mm |
Depth | 11.2mm |
Series | TMR |
Load Regulation | 0.01 |
Minimum Temperature | -40°C |
Medical Approved | Yes |
Efficiency | 0.82 |
Maximum Temperature | +85°C |
