TDK-Lambda PXD DC-DC Converter, 5V dc/ 4A Output, 36, 75 V dc Input, 20W, Through Hole, +105°C Max Temp -55°C Min Temp

RS Stock No.:: 204-0578
Mfr. Part No.:: PXD20-48S05
Brand:: TDK-Lambda

TDK-Lambda PXD DC-DC Converter, 5V dc/ 4A Output, 36, 75 V dc Input, 20W, Through Hole, +105°C Max Temp -55°C Min Temp

Available to back order for despatch 12/09/2024

Price Each

£61.74

(exc. VAT)

£74.09

(inc. VAT)

Units	Per unit
1 - 4	£61.74
5 - 9	£59.89
10 - 24	£58.04
25 - 49	£56.18
50 +	£54.33

RS Stock No.:: 204-0578
Mfr. Part No.:: PXD20-48S05
Brand:: TDK-Lambda

Technical Reference

Datasheet - PXD-20-48S-05

Legislation and Compliance

COO (Country of Origin):: TW

Product Details

The TDK-Lambda PXD20-xxDxx dual output series offers 20 watts of output power from a 2 x 1 x 0.4 inch package. This series has a 2:1 wide input voltage of 9-18, 18-36, or 36-75VDC , and features 1600VDC of isolation, short-circuit , and over-voltage protection.

https://product.tdk.com/info/en/catalog/datasheets/pxd_e.pdf

Specifications

Attribute	Value
Output Voltage	5V dc
Input Voltage Range	36, 75 V dc
Power Rating	20W
Input Voltage Nominal	36 V dc
Output Current	4A
Mounting Type	Through Hole
Number of Outputs	1
Output Voltage Adjustment Range	±10%
Isolation Voltage	1.6kV
Length	2in
Width	1in
Railway Approved	No
Series	PXD
Load Regulation	0.005
Efficiency	0.89
Maximum Temperature	+105°C
Minimum Temperature	-55°C
Medical Approved	No
