TDK-Lambda CC-E DC-DC Converter, 12V dc/ 0.25A Output, 4.5, 9 V dc Input, 3W, Through Hole, +85°C Max Temp -40°C Min
- RS Stock No.:
- 204-0395
- Mfr. Part No.:
- CC3-2412SS-E
- Brand:
- TDK-Lambda
Bulk discount available
Subtotal (1 tray of 10 units)*
£157.98
(exc. VAT)
£189.58
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 11 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tray(s) | Per Tray | Per unit* |
---|---|---|
1 - 4 | £157.98 | £15.798 |
5 - 9 | £153.24 | £15.324 |
10 - 24 | £148.50 | £14.85 |
25 - 49 | £143.76 | £14.376 |
50 + | £139.02 | £13.902 |
*price indicative
- RS Stock No.:
- 204-0395
- Mfr. Part No.:
- CC3-2412SS-E
- Brand:
- TDK-Lambda
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TDK-Lambda | |
Output Voltage | 12V dc | |
Input Voltage Range | 4.5, 9 V dc | |
Power Rating | 3W | |
Input Voltage Nominal | 24 V dc | |
Output Current | 0.25A | |
Mounting Type | Through Hole | |
Isolated | Yes | |
Number of Outputs | 1 | |
Output Voltage Adjustment Range | ±3% | |
Package | SIP | |
Isolation Voltage | 500V | |
Width | 22.8mm | |
Depth | 16.6mm | |
Railway Approved | No | |
Series | CC-E | |
Load Regulation | 100mV | |
Maximum Temperature | +85°C | |
Medical Approved | No | |
Efficiency | 0.82 | |
Minimum Temperature | -40°C | |
Select all | ||
---|---|---|
Brand TDK-Lambda | ||
Output Voltage 12V dc | ||
Input Voltage Range 4.5, 9 V dc | ||
Power Rating 3W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 0.25A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range ±3% | ||
Package SIP | ||
Isolation Voltage 500V | ||
Width 22.8mm | ||
Depth 16.6mm | ||
Railway Approved No | ||
Series CC-E | ||
Load Regulation 100mV | ||
Maximum Temperature +85°C | ||
Medical Approved No | ||
Efficiency 0.82 | ||
Minimum Temperature -40°C | ||
