TDK-Lambda CC-E DC-DC Converter, 3.3V dc/ 0.4A Output, 4.5, 9.0 V dc Input, 1.5W, Through Hole, +85°C Max Temp -40°C
- RS Stock No.:
- 204-0332
- Mfr. Part No.:
- CC1R5-0503SR-E
- Brand:
- TDK-Lambda
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 204-0332
- Mfr. Part No.:
- CC1R5-0503SR-E
- Brand:
- TDK-Lambda
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK-Lambda | |
| Output Voltage | 3.3V dc | |
| Input Voltage Range | 4.5, 9.0 V dc | |
| Power Rating | 1.5W | |
| Input Voltage Nominal | 5 V dc | |
| Output Current | 0.4A | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | ±3% | |
| Package | SMD | |
| Isolation Voltage | 500V | |
| Depth | 16.6mm | |
| Width | 16.5mm | |
| Railway Approved | No | |
| Series | CC-E | |
| Load Regulation | 40mV | |
| Medical Approved | No | |
| Efficiency | 0.71 | |
| Maximum Temperature | +85°C | |
| Minimum Temperature | -40°C | |
Select all | ||
|---|---|---|
Brand TDK-Lambda | ||
Output Voltage 3.3V dc | ||
Input Voltage Range 4.5, 9.0 V dc | ||
Power Rating 1.5W | ||
Input Voltage Nominal 5 V dc | ||
Output Current 0.4A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range ±3% | ||
Package SMD | ||
Isolation Voltage 500V | ||
Depth 16.6mm | ||
Width 16.5mm | ||
Railway Approved No | ||
Series CC-E | ||
Load Regulation 40mV | ||
Medical Approved No | ||
Efficiency 0.71 | ||
Maximum Temperature +85°C | ||
Minimum Temperature -40°C | ||
