TRACOPOWER THM 10WI DC-DC Converter, ±12V dc/ 416mA Output, 18 → 75 V dc Input, 10W, Through Hole, +90°C Max
- RS Stock No.:
- 200-8475
- Distrelec Article No.:
- 300-08-510
- Mfr. Part No.:
- THM 10-4822WI
- Brand:
- TRACOPOWER
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 200-8475
- Distrelec Article No.:
- 300-08-510
- Mfr. Part No.:
- THM 10-4822WI
- Brand:
- TRACOPOWER
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | ±12V dc | |
| Input Voltage Range | 18 → 75 V dc | |
| Power Rating | 10W | |
| Input Voltage Nominal | 48 V dc | |
| Output Current | 416mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 2 | |
| Package | DIP | |
| Isolation Voltage | 5kV dc | |
| Length | 31.8mm | |
| Width | 20.3mm | |
| Depth | 10.2mm | |
| Railway Approved | No | |
| Series | THM 10WI | |
| Load Regulation | 0.01 | |
| Maximum Temperature | +90°C | |
| Minimum Temperature | -40°C | |
| Medical Approved | Yes | |
| Efficiency | 0.88 | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage ±12V dc | ||
Input Voltage Range 18 → 75 V dc | ||
Power Rating 10W | ||
Input Voltage Nominal 48 V dc | ||
Output Current 416mA | ||
Mounting Type Through Hole | ||
Number of Outputs 2 | ||
Package DIP | ||
Isolation Voltage 5kV dc | ||
Length 31.8mm | ||
Width 20.3mm | ||
Depth 10.2mm | ||
Railway Approved No | ||
Series THM 10WI | ||
Load Regulation 0.01 | ||
Maximum Temperature +90°C | ||
Minimum Temperature -40°C | ||
Medical Approved Yes | ||
Efficiency 0.88 | ||
