TRACOPOWER TEL 10 DC-DC Converter, 5.1V dc/ 2A Output, 18 → 36 V dc Input, 10W, Through Hole, +78°C Max Temp
- RS Stock No.:
- 187-5074
- Mfr. Part No.:
- TEL 10-2411
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£23.00
(exc. VAT)
£27.60
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 19 unit(s) shipping from 30 October 2025
- Plus 10 unit(s) shipping from 20 November 2025
- Plus 10 unit(s) shipping from 22 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £23.00 |
| 5 - 9 | £22.31 |
| 10 - 24 | £21.62 |
| 25 - 49 | £20.70 |
| 50 + | £19.78 |
*price indicative
- RS Stock No.:
- 187-5074
- Mfr. Part No.:
- TEL 10-2411
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | 5.1V dc | |
| Input Voltage Range | 18 → 36 V dc | |
| Power Rating | 10W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 2A | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Package | DIP | |
| Isolation Voltage | 1kV dc | |
| Length | 23.8mm | |
| Width | 13.7mm | |
| Depth | 8mm | |
| Series | TEL 10 | |
| Load Regulation | 0.01 | |
| Maximum Temperature | +78°C | |
| Minimum Temperature | -40°C | |
| Efficiency | 83% | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 5.1V dc | ||
Input Voltage Range 18 → 36 V dc | ||
Power Rating 10W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 2A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package DIP | ||
Isolation Voltage 1kV dc | ||
Length 23.8mm | ||
Width 13.7mm | ||
Depth 8mm | ||
Series TEL 10 | ||
Load Regulation 0.01 | ||
Maximum Temperature +78°C | ||
Minimum Temperature -40°C | ||
Efficiency 83% | ||
- COO (Country of Origin):
- TW
The TEL 10 series is a range of isolated 10 Watt DC/DC converters which come in a ultra compact DIP-16 metal package. The design purpose of these series was to miniaturized low power DC/DC converters to the maximum without sacrificing high efficiency. The TEL 10 series sets the new standard for power density with 3.83 W/cm3. The TEL 10 series offers a wide 2:1 input voltage range and features a high efficiency of up to 88% which enables an operation temperature of up to +70°C at full load and up to 85°C with 50% load. The converters have an internal input filter. The TEL 10 Series models feature an overall economical solution for space critical and cost sensitive applications in instrumentation, IT and industrial electronics.
Most compact 10 Watt converter in DIP-16 metal casing
Highest power density of 3.83 W/cm3
6-side shielded metal case with insulated base plate
Wide 2:1 input voltage range
High efficiency for low thermal loss
Operating temperature range of -40°C to +88°C
Current limitation and protection against short circuit
Highest power density of 3.83 W/cm3
6-side shielded metal case with insulated base plate
Wide 2:1 input voltage range
High efficiency for low thermal loss
Operating temperature range of -40°C to +88°C
Current limitation and protection against short circuit
