Name: TRACOPOWER THN 15N DC-DC Converter, 12V dc/ 1.3A Output, 18 → 36 V dc Input, 15W, Through Hole, +105°C Max Temp
Brand: TRACOPOWER
SKU: 183-0748
Price: 40.96 GBP
Availability: InStock

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	TRACOPOWER
	Output Voltage	12V dc
	Input Voltage Range	18 → 36 V dc
	Power Rating	15W
	Input Voltage Nominal	24 V dc
	Output Current	1.3A
	Mounting Type	Through Hole
	Isolated	Yes
	Number of Outputs	1
	Package	1 x 1 in
	Isolation Voltage	1.6kV dc
	Length	25.4mm
	Depth	9.9mm
	Width	25.4mm
	Series	THN 15N
	Load Regulation	0.002
	Maximum Temperature	+105°C
	Standards Met	EN 55024, EN 55032, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC/EN/UL 62368-1, UL 94V-0
	Efficiency	89%
	Minimum Temperature	-40°C

	Select all
	Brand TRACOPOWER
	Output Voltage 12V dc
	Input Voltage Range 18 → 36 V dc
	Power Rating 15W
	Input Voltage Nominal 24 V dc
	Output Current 1.3A
	Mounting Type Through Hole
	Isolated Yes
	Number of Outputs 1
	Package 1 x 1 in
	Isolation Voltage 1.6kV dc
	Length 25.4mm
	Depth 9.9mm
	Width 25.4mm
	Series THN 15N
	Load Regulation 0.002
	Maximum Temperature +105°C
	Standards Met EN 55024, EN 55032, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC/EN/UL 62368-1, UL 94V-0
	Efficiency 89%
	Minimum Temperature -40°C

COO (Country of Origin):: TW

TRACOPOWER THN 15N Series DC-DC Converter, 18 to 36V DC Input Voltage Range, 15W Power Rating - THN 15-2412N

This isolated DC-DC converter effectively manages power in a compact design, making it essential for various electronic applications. It ensures reliable voltage conversion while maintaining stability over a wide input voltage range. The robust metal housing enhances its durability and allows for effective heat dissipation during operation.

Features & Benefits

• Space-saving compact design suitable for PCB layouts
• High efficiency of up to 91% reduces energy loss
• Wide input voltage range provides application flexibility
• Isolation voltage of 1.6 kV DC enhances safety
• Overload and short circuit protection improve the durability of the device
• Low no-load power consumption optimises energy usage

Applications

• Power supply for mobile equipment
• Suitable for instrumentation that requires stable voltage
• Utilised in distributed power architectures within communication systems
• Employed in industrial electronics to enhance efficiency
• Ideal for scenarios where PCB space is critically limited

Can it be used in high-temperature environments?

Yes, it operates effectively within a temperature range of -40 to +70°C without derating.

How does the output voltage adjustment work?

The output voltage can be fine-tuned using an external trim resistor, allowing for precise adjustments as needed.

What are the typical input current values at no load?

The typical no-load input current is approximately 10mA for 12V models, decreasing with higher input voltages.

What precautions should be taken to ensure safety during usage?

Ensure adequate heat dissipation and comply with input voltage specifications to prevent overload or overheating.

Units	Per unit
1 - 4	£34.13
5 - 9	£33.11
10 - 24	£32.08
25 - 49	£30.72
50 +	£29.36
