XP Power ISM01 DC-DC Converter, ±15V dc/ ±33mA Output, 21.6 → 26.4 V dc Input, 1W, Surface Mount, +95°C Max Temp
- RS Stock No.:
- 174-4646
- Mfr. Part No.:
- ISM0124D15
- Brand:
- XP Power
Bulk discount available
Subtotal (1 tube of 10 units)*
£173.00
(exc. VAT)
£207.60
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 16 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £173.00 | £17.30 |
| 5 - 9 | £167.81 | £16.781 |
| 10 - 24 | £162.62 | £16.262 |
| 25 - 49 | £157.43 | £15.743 |
| 50 + | £152.24 | £15.224 |
*price indicative
- RS Stock No.:
- 174-4646
- Mfr. Part No.:
- ISM0124D15
- Brand:
- XP Power
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | XP Power | |
| Output Voltage | ±15V dc | |
| Input Voltage Range | 21.6 → 26.4 V dc | |
| Power Rating | 1W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | ±33mA | |
| Mounting Type | Surface Mount | |
| Isolated | Yes | |
| Number of Outputs | 2 | |
| Package | SMD | |
| Isolation Voltage | 4kV dc | |
| Depth | 10.2mm | |
| Width | 13.7mm | |
| Length | 18.9mm | |
| Series | ISM01 | |
| Load Regulation | 0.1 | |
| Efficiency | 80% | |
| Medical Approved | Yes | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +95°C | |
| Standards Met | ANSI/AAMI ES 60601-1, CB, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC 60601-1, IPC/JEDEC J-STD-020D.1, MIL-HDBK-217F, UL | |
