XP Power ISM01 DC-DC Converter, 12V dc/ 84mA Output, 4.5 → 5.5 V dc Input, 1W, Surface Mount, +95°C Max Temp
- RS Stock No.:
- 174-4636
- Mfr. Part No.:
- ISM0105S12
- Brand:
- XP Power
Bulk discount available
Subtotal (1 tube of 10 units)*
£160.62
(exc. VAT)
£192.74
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,999 unit(s) shipping from 17 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £160.62 | £16.062 |
| 5 - 9 | £155.81 | £15.581 |
| 10 - 24 | £150.99 | £15.099 |
| 25 - 49 | £146.18 | £14.618 |
| 50 + | £141.36 | £14.136 |
*price indicative
- RS Stock No.:
- 174-4636
- Mfr. Part No.:
- ISM0105S12
- Brand:
- XP Power
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | XP Power | |
| Output Voltage | 12V dc | |
| Input Voltage Range | 4.5 → 5.5 V dc | |
| Power Rating | 1W | |
| Input Voltage Nominal | 5 V dc | |
| Output Current | 84mA | |
| Mounting Type | Surface Mount | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Package | SMD | |
| Isolation Voltage | 4kV dc | |
| Width | 13.7mm | |
| Depth | 10.2mm | |
| Length | 18.9mm | |
| Series | ISM01 | |
| Load Regulation | 0.1 | |
| Standards Met | ANSI/AAMI ES 60601-1, CB, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC 60601-1, IPC/JEDEC J-STD-020D.1, MIL-HDBK-217F, UL | |
| Maximum Temperature | +95°C | |
| Medical Approved | Yes | |
| Minimum Temperature | -40°C | |
| Efficiency | 80% | |
Select all | ||
|---|---|---|
Brand XP Power | ||
Output Voltage 12V dc | ||
Input Voltage Range 4.5 → 5.5 V dc | ||
Power Rating 1W | ||
Input Voltage Nominal 5 V dc | ||
Output Current 84mA | ||
Mounting Type Surface Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package SMD | ||
Isolation Voltage 4kV dc | ||
Width 13.7mm | ||
Depth 10.2mm | ||
Length 18.9mm | ||
Series ISM01 | ||
Load Regulation 0.1 | ||
Standards Met ANSI/AAMI ES 60601-1, CB, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC 60601-1, IPC/JEDEC J-STD-020D.1, MIL-HDBK-217F, UL | ||
Maximum Temperature +95°C | ||
Medical Approved Yes | ||
Minimum Temperature -40°C | ||
Efficiency 80% | ||
