Cosel MGF DC/DC Converter, 15V dc, -15 V dc/ 200 mA, 24V dc Input, 9V Input 6 W, PCB, 85 °C Max Temp -40 °C Min Temp,
- RS Stock No.:
- 171-4848
- Mfr. Part No.:
- MGFW62415
- Brand:
- Cosel
Subtotal (1 tube of 10 units)*
£212.42
(exc. VAT)
£254.90
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 10 March 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £212.42 | £21.242 |
*price indicative
- RS Stock No.:
- 171-4848
- Mfr. Part No.:
- MGFW62415
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 15, -15V dc | |
| Minimum Input Voltage | 9V | |
| Maximum Input Voltage | 24V dc | |
| Output Current 1 | 200mA | |
| Output Current 2 | 0.2A | |
| Mount Type | PCB | |
| Output Voltage 2 | 15V dc | |
| Number of Outputs | 2 | |
| Ripple and Noise | 500mV Pk-Pk | |
| Output Voltage Adjustment Range | 14.55 to 15.45 V | |
| Number of Pins | 7 | |
| Isolation Voltage | 1kV dc | |
| Package Type | SIP-8 | |
| Maximum Output Power | 6W | |
| Width | 9.5mm | |
| Standards/Approvals | cUL, UL62368-1, CSA, EN 62368-1, RoHS, CE, UL60950-1, UKCA, C-UL, EN62368-1 | |
| Depth | 12mm | |
| Length | 22mm | |
| Series | MGF | |
| Weight | 7g | |
| Efficiency | 88% | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Product Type DC/DC Converter | ||
Output Voltage 1 15, -15V dc | ||
Minimum Input Voltage 9V | ||
Maximum Input Voltage 24V dc | ||
Output Current 1 200mA | ||
Output Current 2 0.2A | ||
Mount Type PCB | ||
Output Voltage 2 15V dc | ||
Number of Outputs 2 | ||
Ripple and Noise 500mV Pk-Pk | ||
Output Voltage Adjustment Range 14.55 to 15.45 V | ||
Number of Pins 7 | ||
Isolation Voltage 1kV dc | ||
Package Type SIP-8 | ||
Maximum Output Power 6W | ||
Width 9.5mm | ||
Standards/Approvals cUL, UL62368-1, CSA, EN 62368-1, RoHS, CE, UL60950-1, UKCA, C-UL, EN62368-1 | ||
Depth 12mm | ||
Length 22mm | ||
Series MGF | ||
Weight 7g | ||
Efficiency 88% | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
- COO (Country of Origin):
- JP
The Cosel high-efficiency isolated DC-DC converter designed for PCB mount applications, offering a reliable solution for power conversion in Compact electronic devices.
Remote ON/OFF feature enhances control over power management
Integrated overcurrent protection ensures reliability and safety under load
RoHS Regulations
