Cosel MGS DC/DC Converter, 3.3V dc/ 1.6 A, 24V dc Input, 24V dc Input 5.28 W, PCB, 85 °C Max Temp -40 °C Min Temp SIP-8
- RS Stock No.:
- 171-4713
- Mfr. Part No.:
- MGS6243R3
- Brand:
- Cosel
Bulk discount available
View bulk pricing optionsSubtotal (1 tube of 10 units)*
£155.27
(exc. VAT)
£186.32
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 08 March 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £155.27 | £15.527 |
| 5 - 9 | £150.59 | £15.059 |
| 10 - 24 | £147.49 | £14.749 |
| 25 - 49 | £144.38 | £14.438 |
| 50 + | £141.28 | £14.128 |
*price indicative
- RS Stock No.:
- 171-4713
- Mfr. Part No.:
- MGS6243R3
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 3.3V dc | |
| Maximum Input Voltage | 24V dc | |
| Minimum Input Voltage | 24V dc | |
| Output Current 1 | 1.6A | |
| Mount Type | PCB | |
| Number of Outputs | 1 | |
| Isolation Voltage | 1kV dc | |
| Package Type | SIP-8 | |
| Maximum Output Power | 5.28W | |
| Length | 22mm | |
| Depth | 12mm | |
| Series | MGS | |
| Weight | 7g | |
| Standards/Approvals | cUL, EN 62368-1, RoHS, UL 60950-1 | |
| Width | 9.5mm | |
| Maximum Operating Temperature | 85°C | |
| Efficiency | 82% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Product Type DC/DC Converter | ||
Output Voltage 1 3.3V dc | ||
Maximum Input Voltage 24V dc | ||
Minimum Input Voltage 24V dc | ||
Output Current 1 1.6A | ||
Mount Type PCB | ||
Number of Outputs 1 | ||
Isolation Voltage 1kV dc | ||
Package Type SIP-8 | ||
Maximum Output Power 5.28W | ||
Length 22mm | ||
Depth 12mm | ||
Series MGS | ||
Weight 7g | ||
Standards/Approvals cUL, EN 62368-1, RoHS, UL 60950-1 | ||
Width 9.5mm | ||
Maximum Operating Temperature 85°C | ||
Efficiency 82% | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- JP
The Cosel DC-DC converter delivers reliable power conversion with excellent isolation capabilities, designed to meet various demanding electrical environments. Its efficient output performance enhances application versatility across a range of operational demands.
Provides DC-input range of 18 to 36V and 36 to 76V for versatile applications
Delivers output power of 5.28W with dual, adjustable voltage outputs
Achieves high efficiency ratings of up to 89% for optimal energy performance
Incorporates comprehensive overcurrent protection to ensure device safety
