Cosel MGS DC/DC Converter, 15V dc/ 100 mA, 48V dc Input, 48V dc Input 1.5 W, PCB, 85 °C Max Temp -40 °C Min Temp SIP-6
- RS Stock No.:
- 171-4682
- Mfr. Part No.:
- MGS1R54815
- Brand:
- Cosel
Bulk discount available
View bulk pricing optionsSubtotal (1 tube of 10 units)*
£98.78
(exc. VAT)
£118.54
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 08 March 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £98.78 | £9.878 |
| 5 - 9 | £95.81 | £9.581 |
| 10 - 24 | £93.84 | £9.384 |
| 25 - 49 | £91.86 | £9.186 |
| 50 + | £89.89 | £8.989 |
*price indicative
- RS Stock No.:
- 171-4682
- Mfr. Part No.:
- MGS1R54815
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Output Voltage 1 | 15V dc | |
| Product Type | DC/DC Converter | |
| Maximum Input Voltage | 48V dc | |
| Minimum Input Voltage | 48V dc | |
| Output Current 1 | 100mA | |
| Mount Type | PCB | |
| Number of Outputs | 1 | |
| Isolation Voltage | 1kV dc | |
| Package Type | SIP-6 | |
| Maximum Output Power | 1.5W | |
| Standards/Approvals | cUL, EN 62368-1, RoHS, UL 60950-1 | |
| Width | 8.5mm | |
| Series | MGS | |
| Weight | 4g | |
| Length | 17mm | |
| Depth | 12mm | |
| Maximum Operating Temperature | 85°C | |
| Efficiency | 82% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Output Voltage 1 15V dc | ||
Product Type DC/DC Converter | ||
Maximum Input Voltage 48V dc | ||
Minimum Input Voltage 48V dc | ||
Output Current 1 100mA | ||
Mount Type PCB | ||
Number of Outputs 1 | ||
Isolation Voltage 1kV dc | ||
Package Type SIP-6 | ||
Maximum Output Power 1.5W | ||
Standards/Approvals cUL, EN 62368-1, RoHS, UL 60950-1 | ||
Width 8.5mm | ||
Series MGS | ||
Weight 4g | ||
Length 17mm | ||
Depth 12mm | ||
Maximum Operating Temperature 85°C | ||
Efficiency 82% | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- JP
The Cosel DC-DC Converter is designed for PCB mounting, providing reliable voltage conversion with isolation. It functions efficiently in various electronic applications, ensuring stability and safety in operation.
High efficiency of 81% typical performance across operational ranges
Input voltage range of DC18 to 36V with surge capability up to 50V
Output voltage adjustable between 3.3V and 15V to cater to diverse requirements
Compliant with safety standards including UL60950-1 and EN62368-1
