TRACOPOWER TIM 3.5 DC-DC Converter, 12V dc/ 292mA Output, 9 → 18 V dc Input, 3.5W, Surface Mount
- RS Stock No.:
- 152-7080
- Mfr. Part No.:
- TIM 3.5-1212SM
- Brand:
- TRACOPOWER
40 In stock - FREE next working day delivery available
Price Each
£31.82
(exc. VAT)
£38.18
(inc. VAT)
Units | Per unit |
|---|---|
| 1 - 4 | £31.82 |
| 5 - 9 | £30.87 |
| 10 - 24 | £29.91 |
| 25 - 49 | £28.64 |
| 50 + | £27.37 |
- RS Stock No.:
- 152-7080
- Mfr. Part No.:
- TIM 3.5-1212SM
- Brand:
- TRACOPOWER
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
Medical/Reinforced I/O-Isolation DC/DC Converters 2 - 30 Watt
3.5 Watt DC/DC converter in SMD-16 package
Certification to IEC/ES 60601-1 3rd edition for 2 x MOPP
I/O isolation 5000 VACrms rated for 250 VACrms working voltage
Risk management file acc. ISO 14971
Quality to ISO 13485, IPC-A-610 level 3
5-year product warranty
2:1 input voltage with extended low input range:4.5-12, 9-18, 18-36, 36-75
Output voltages:5.0, 12, 15, 24, ±12, ±15 VDC
I/O isolation 5000 VACrms rated for 250 VACrms working voltage
Low leakage current
Input filter to meet EN55022 class A
I/O isolation 5000 VACrms rated for 250 VACrms working voltage
Risk management file acc. ISO 14971
Quality to ISO 13485, IPC-A-610 level 3
5-year product warranty
2:1 input voltage with extended low input range:4.5-12, 9-18, 18-36, 36-75
Output voltages:5.0, 12, 15, 24, ±12, ±15 VDC
I/O isolation 5000 VACrms rated for 250 VACrms working voltage
Low leakage current
Input filter to meet EN55022 class A
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 9 → 18 V dc |
| Power Rating | 3.5W |
| Input Voltage Nominal | 12 V dc |
| Output Current | 292mA |
| Mounting Type | Surface Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | SMD 16 |
| Isolation Voltage | 5kV ac |
| Length | 24.3mm |
| Depth | 10.5mm |
| Width | 14.4mm |
| Series | TIM 3.5 |
| Medical Approved | Yes |
| Efficiency | 82% |
| Standards Met | EN 55022, IEC/EN/ES 60601-1 |
