XP Power DC-DC Converter, 24V dc/ 375mA Output, 36 → 75 V dc Input, 9W, Through Hole
- RS Stock No.:
- 138-9545
- Mfr. Part No.:
- ICZ0948S24
- Brand:
- XP Power
Save 11% when you buy 50 units
Subtotal (1 unit)*
£24.02
(exc. VAT)
£28.82
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 07 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £24.02 |
5 - 9 | £23.30 |
10 - 24 | £22.58 |
25 - 49 | £21.86 |
50 + | £21.14 |
*price indicative
- RS Stock No.:
- 138-9545
- Mfr. Part No.:
- ICZ0948S24
- Brand:
- XP Power
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | XP Power | |
Output Voltage | 24V dc | |
Input Voltage Range | 36 → 75 V dc | |
Power Rating | 9W | |
Input Voltage Nominal | 36 → 75 V dc | |
Output Current | 375mA | |
Mounting Type | Through Hole | |
Isolated | Yes | |
Number of Outputs | 1 | |
Package | SIP 8 | |
Isolation Voltage | 1.6kV dc | |
Efficiency | 89% | |
Select all | ||
---|---|---|
Brand XP Power | ||
Output Voltage 24V dc | ||
Input Voltage Range 36 → 75 V dc | ||
Power Rating 9W | ||
Input Voltage Nominal 36 → 75 V dc | ||
Output Current 375mA | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package SIP 8 | ||
Isolation Voltage 1.6kV dc | ||
Efficiency 89% | ||
- COO (Country of Origin):
- TW
Ultra Compact SIP-8 Package
Smallest Footprint 9 W Converter
Single & Dual Outputs
2:1 Input Range
Operating Temperature -40 °C to +85 °C
1600 VDC Input to Output Isolation
Fully Regulated Output
No Minimum Load Required
Remote On/Off
3 Year Warranty
Smallest Footprint 9 W Converter
Single & Dual Outputs
2:1 Input Range
Operating Temperature -40 °C to +85 °C
1600 VDC Input to Output Isolation
Fully Regulated Output
No Minimum Load Required
Remote On/Off
3 Year Warranty
