TRACOPOWER TRN 3SM DC-DC Converter, ±5V dc/ ±300mA Output, 9 → 18 V dc Input, 3W, Surface Mount, +85°C Max Temp

View all DC-DC Converters
Bulk discount available

Subtotal (1 unit)*

£19.96

(exc. VAT)

£23.95

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 2 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£19.96
5 - 9£19.36
10 - 24£18.77
25 - 49£17.96
50 +£17.17

*price indicative

RS Stock No.:
137-3123
Mfr. Part No.:
TRN 3-1221SM
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Output Voltage

±5V dc

Input Voltage Range

9 → 18 V dc

Power Rating

3W

Input Voltage Nominal

12 V dc

Output Current

±300mA

Mounting Type

Surface Mount

Isolated

Yes

Number of Outputs

2

Package

SMD

Isolation Voltage

1.6kV dc

Length

11.9mm

Depth

7.6mm

Width

11.3mm

Series

TRN 3SM

Load Regulation

0.01

Efficiency

78%

Minimum Temperature

-40°C

Maximum Temperature

+85°C

COO (Country of Origin):
TW
The TRN 3SM Series comprises 3 Watt fully regulated, high performance DC/DC converters. They come in a compact cubical package of only 1.07 cm3. Full load operation is reliable up tp 85°C environment temperature. With 1’600 VDC I/O-isolation voltage, and short current protection they cover a wide range of application when space is limited. The input of the converters is designed for a wide voltage range (2:1) and minimum load is not required. The functional I/O-isolation system is designed to meet IEC/EN 62368-1 with a test voltage (60 s) of 1600 VDC.
