TRACOPOWER THM 30 WI DC/DC Converter, 24V dc/ 1.25 A, 36V dc Input, 9V Input 30 W, PCB, 80 °C Max Temp -40 °C Min Temp 2

View all DC-DC Converters
Bulk discount available

Subtotal (1 unit)*

£86.93

(exc. VAT)

£104.32

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 17 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
1 - 4£86.93
5 - 9£84.31
10 - 24£81.72
25 - 49£78.23
50 +£74.76

*price indicative

RS Stock No.:
135-1590
Mfr. Part No.:
THM 30-2415WI
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Product Type

DC/DC Converter

Output Voltage 1

24V dc

Maximum Input Voltage

36V dc

Minimum Input Voltage

9V

Output Current 1

1.25A

Mount Type

PCB

Input Ratio

4:1

MTBF

1137000h

Number of Outputs

1

Output Voltage Adjustment Range

21.6/28.8 V dc

Isolation Voltage

5kV ac

Maximum Output Power

30W

Package Type

2 x 1 in

Depth

10.2mm

Width

25.4mm

Length

50.8mm

Standards/Approvals

No

Series

THM 30 WI

Efficiency

90%

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

80°C

Traco Power DC-DC Converter, 5kV AC Isolation Voltage, 4:1 Input Ratio - THM 30 WI Series - THM 30-2415WI


Make sure your power supply hits the mark with this DC-DC converter from Traco Power. It takes a wide input range between 9 and 36V DC, making it a versatile option. After conversion, you GET a 24V DC output that works with standard motors, instruments and control applications. The unit's built to handle temperatures between -40°C and +80°C without breaking a sweat, so you can Trust it takes challenging conditions in its stride.

Features & Benefits


• Through-hole pins for dependable mounting on a PCB

• Reinforced insulation protects users against shocks

• 90% efficiency to keep waste heat to a minimum

Applications


• Medical equipment

• Process control

• Telecommunications

Is this DC-DC converter suitable for portable devices?


Yes. It has a small footprint of 25.4 (L) x 50.8 (W) x 10.2mm (D) to save space inside Compact electronics. It features a remote on-and-off function for power-saving in battery-powered equipment. As it weighs 32g, it doesn't add unnecessary weight.

Is this DC-DC converter safe for medical equipment used by patients?


Low current leakage of 2.5μA means the unit keeps equipment touch-safe. As it meets the European standard EN 60601-1 for medical electrical equipment, you can be sure it's safe for devices used by patients.
