Cosel STMGFW DC-DC Converter, ±24V dc/ 650mA Output, 9 → 36 V dc Input, 15W, PCB Mount, +70°C Max Temp -20°C Min
- RS Stock No.:
- 132-7510
- Mfr. Part No.:
- STMGFW152412
- Brand:
- Cosel
Bulk discount available
Subtotal (1 unit)*
£71.50
(exc. VAT)
£85.80
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 8 unit(s) ready to ship
- Plus 999,999,991 unit(s) shipping from 19 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £71.50 |
5 - 9 | £69.36 |
10 - 24 | £67.92 |
25 - 49 | £66.50 |
50 + | £65.07 |
*price indicative
- RS Stock No.:
- 132-7510
- Mfr. Part No.:
- STMGFW152412
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Cosel | |
Output Voltage | ±24V dc | |
Input Voltage Range | 9 → 36 V dc | |
Power Rating | 15W | |
Input Voltage Nominal | 24 V dc | |
Output Current | 650mA | |
Mounting Type | PCB Mount | |
Isolated | Yes | |
Number of Outputs | 2 | |
Output Voltage Adjustment Range | 11.76 → 12.5V | |
Isolation Voltage | 500V dc | |
Depth | 27mm | |
Length | 93mm | |
Width | 52mm | |
Series | STMGFW | |
Load Regulation | 600mV | |
Minimum Temperature | -20°C | |
Standards Met | CE, cUL, EN 60950-1 Complies, UL 60950-1 | |
Maximum Temperature | +70°C | |
Efficiency | 88% | |
Select all | ||
---|---|---|
Brand Cosel | ||
Output Voltage ±24V dc | ||
Input Voltage Range 9 → 36 V dc | ||
Power Rating 15W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 650mA | ||
Mounting Type PCB Mount | ||
Isolated Yes | ||
Number of Outputs 2 | ||
Output Voltage Adjustment Range 11.76 → 12.5V | ||
Isolation Voltage 500V dc | ||
Depth 27mm | ||
Length 93mm | ||
Width 52mm | ||
Series STMGFW | ||
Load Regulation 600mV | ||
Minimum Temperature -20°C | ||
Standards Met CE, cUL, EN 60950-1 Complies, UL 60950-1 | ||
Maximum Temperature +70°C | ||
Efficiency 88% | ||
- COO (Country of Origin):
- JP
STMGFW Series
The STMGFW Series of Cosel DC-DC converters provide a massive range of power ratings and output voltages making them versatile and suitable for many applications. The STMGFW converters are highly reliable power supplies offering great quality. 5 Year Warranty
Features and Benefits
• Isolated unit type DC-DC converter
• Wide input voltage DC9-36V/DC18-76V
• Available connector interface (optional)
• Available case cover (optional)
• Available DIN Rail attachment (optional)
• Built in Overcurrent protection (recovery automatically)
• Built in Overvoltage protection (for STMG30)
• Built in Remote ON/OFF
• Built in Output voltage adjustment (for single output, ±10%)
• Wide input voltage DC9-36V/DC18-76V
• Available connector interface (optional)
• Available case cover (optional)
• Available DIN Rail attachment (optional)
• Built in Overcurrent protection (recovery automatically)
• Built in Overvoltage protection (for STMG30)
• Built in Remote ON/OFF
• Built in Output voltage adjustment (for single output, ±10%)
