Cosel DBS DC-DC Converter, 3.3V dc/ 50A Output, 200 → 400 V dc Input, 165W, PCB Mount, +85°C Max Temp -20°C Min
- RS Stock No.:
- 132-5415
- Mfr. Part No.:
- DBS200B03
- Brand:
- Cosel
Available to back order for despatch 20/09/2024
Added
Price Each
£169.46
(exc. VAT)
£203.35
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £169.46 |
| 5 - 9 | £164.38 |
| 10 - 24 | £160.99 |
| 25 - 49 | £157.60 |
| 50 + | £154.21 |
- RS Stock No.:
- 132-5415
- Mfr. Part No.:
- DBS200B03
- Brand:
- Cosel
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
DBS Series
The Cosel DBS series of DC-DC converters offer a wide range of power ratings and output voltages making them versatile and suitable for many applications. Extra features include remote sensing, remote on/off, overcurrent and overvoltage protection; ideal for distributed power systems.
Features and Benefits
• Thin and small in size
• Built-in overcurrent, overvoltage and thermal protection circuits
• Built-in remote ON/OFF (On both side of input and output)
• Inverter operating monitoring (IOG)
• Mounting hole (M3 tapped)
• N+1 redundant operation
• Built-in overcurrent, overvoltage and thermal protection circuits
• Built-in remote ON/OFF (On both side of input and output)
• Inverter operating monitoring (IOG)
• Mounting hole (M3 tapped)
• N+1 redundant operation
Cosel Isolated DC-DC Converters
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 3.3V dc |
| Input Voltage Range | 200 → 400 V dc |
| Power Rating | 165W |
| Input Voltage Nominal | 280 V dc |
| Output Current | 50A |
| Mounting Type | PCB Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Output Voltage Adjustment Range | 3.25 → 3.45V |
| Isolation Voltage | 3 kV ac, 500V dc |
| Depth | 12.7mm |
| Width | 61mm |
| Length | 116.8mm |
| Series | DBS |
| Load Regulation | 30mV |
| Standards Met | CE, cUL, cULus Recognised, EN 50178 Complies with DEN-AN & IEC 60950-1, EN 60950-1, UL 60950-1 |
| Maximum Temperature | +85°C |
| Efficiency | 79% |
| Minimum Temperature | -20°C |
