TDK-Lambda CC-E DC-DC Converter, 12V dc/ 250mA Output, 9 → 18 V dc Input, 3W, Surface Mount, +85°C Max Temp

RS Stock No.:: 126-3534
Mfr. Part No.:: CC3-1212SR-E
Brand:: TDK-Lambda

TDK-Lambda CC-E DC-DC Converter, 12V dc/ 250mA Output, 9 → 18 V dc Input, 3W, Surface Mount, +85°C Max Temp

Price Each**

£11.18

(exc. VAT)

£13.42

(inc. VAT)

Available to back order for despatch 22/05/2025*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over £50.00

Units	Per unit
1 - 4	£11.18
5 - 9	£10.86
10 - 24	£10.51
25 - 49	£10.17
50 +	£9.84

**price indicative

RS Stock No.:: 126-3534
Mfr. Part No.:: CC3-1212SR-E
Brand:: TDK-Lambda

CC-E Series_EN_datasheet

Attribute	Value
Output Voltage	12V dc
Input Voltage Range	9 → 18 V dc
Power Rating	3W
Input Voltage Nominal	12 V dc
Output Current	250mA
Mounting Type	Surface Mount
Isolated	Yes
Number of Outputs	1
Output Voltage Adjustment Range	11.4 → 15V
Package	DIP
Isolation Voltage	500V ac
Width	16.6mm
Length	22.86mm
Depth	8.8mm
Series	CC-E
Load Regulation	100mV
Efficiency	82%
Standards Met	CE, cULus, EN 60950-1, NEMKO, UL/CSA 60950-1
Minimum Temperature	-40°C
Maximum Temperature	+85°C

TDK-Lambda CC-E DC-DC Converter, 12V dc/ 250mA Output, 9 → 18 V dc Input, 3W, Surface Mount, +85°C Max Temp

FREE delivery for orders over £50.00

CC-E Series, 1 W to 12 W Single/Dual Output

Features and Benefits
