XP Power CA DC-DC Converter, -1.2kV/ 800μA Output, 11.5 → 15.5 V dc Input, 1W, PCB Mount, +50°C Max Temp -10°C
- RS Stock No.:
- 123-8382
- Distrelec Article No.:
- 302-41-403
- Mfr. Part No.:
- CA12N
- Brand:
- XP Power
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 123-8382
- Distrelec Article No.:
- 302-41-403
- Mfr. Part No.:
- CA12N
- Brand:
- XP Power
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | XP Power | |
Output Voltage | -1.2kV | |
Input Voltage Range | 11.5 → 15.5 V dc | |
Power Rating | 1W | |
Input Voltage Nominal | 12 V dc | |
Output Current | 800µA | |
Mounting Type | PCB Mount | |
Isolated | No | |
Number of Outputs | 1 | |
Width | 27.94mm | |
Length | 44.45mm | |
Series | CA | |
Load Regulation | 0.00005 | |
Maximum Temperature | +50°C | |
Minimum Temperature | -10°C | |
Select all | ||
---|---|---|
Brand XP Power | ||
Output Voltage -1.2kV | ||
Input Voltage Range 11.5 → 15.5 V dc | ||
Power Rating 1W | ||
Input Voltage Nominal 12 V dc | ||
Output Current 800µA | ||
Mounting Type PCB Mount | ||
Isolated No | ||
Number of Outputs 1 | ||
Width 27.94mm | ||
Length 44.45mm | ||
Series CA | ||
Load Regulation 0.00005 | ||
Maximum Temperature +50°C | ||
Minimum Temperature -10°C | ||
- COO (Country of Origin):
- US
XP Power DC-High Voltage DC Non Isolated Coverters CA Series
Fully programmable, precise regulation, CA series converters. CA series are high performing, high-voltage power supply products with low noise levels.
Features and Benefits
Minimum ripple lowest 5PPM
Precision regulated
Shielded case
Voltage monitor/Readback
High-level stability
Wide input voltage range
Short circuit, arc protected
EMI/RFI very low
Precision on board reference
Potentiometer or external voltage programming
Calibration adjustment access
Sealed converter - withstands immersion cleaning processes
Reliable
Precision regulated
Shielded case
Voltage monitor/Readback
High-level stability
Wide input voltage range
Short circuit, arc protected
EMI/RFI very low
Precision on board reference
Potentiometer or external voltage programming
Calibration adjustment access
Sealed converter - withstands immersion cleaning processes
Reliable
Applications:
Photomultiplier Tubes
Avalanche photodiodes
Solid-state detectors
Electrophoresis
EO lenses
Piezo devices
Capacitor charging
Avalanche photodiodes
Solid-state detectors
Electrophoresis
EO lenses
Piezo devices
Capacitor charging
Standards
UL 1950, RoHS
