MEAN WELL DC-DC Converter, 12V dc/ 1.25A Output, 18 → 36 V dc Input, 15W, Chassis Mount, +60°C Max Temp -10°C
- RS Stock No.:
- 183-809
- Mfr. Part No.:
- SD-15B-12
- Brand:
- MEAN WELL
3 In stock - FREE next working day delivery available
2 available from Europe for delivery within 1 working day(s).
Added
Price Each
£16.65
(exc. VAT)
£19.98
(inc. VAT)
Units | Per unit |
1 - 4 | £16.65 |
5 - 9 | £16.24 |
10 - 24 | £15.81 |
25 - 49 | £15.02 |
50 + | £14.01 |
- RS Stock No.:
- 183-809
- Mfr. Part No.:
- SD-15B-12
- Brand:
- MEAN WELL
Technical Reference
Legislation and Compliance
Product Details
Mean Well (SD-15A-XX) Single Output Enclosed Regulated DC-DC Converter
The SD-15 series by Mean Well offers you a reliable device capable of converting a DC source from one voltage level to another via regulated outputs. Easy to install & maintain, brings you reliable industrial power conversion. The SD-15 meets rigorous industrial standards such as EN 55022 Class B.
Features and benefits:
• 2:1 wide input range
• Great protection against short-circuits and overloads/voltages
• Low ripple noise
• Adjustable output voltages for the three types are; 24 V dc is 21- 26.4 V dc; 12 V dc is 10.8 - 13.2 V dc and 5 V dc is 4.75 - 5.5 V dc
• Built-in EMI filter
• LED power-on indicator
• 2-year manufacturer warranty
• Great protection against short-circuits and overloads/voltages
• Low ripple noise
• Adjustable output voltages for the three types are; 24 V dc is 21- 26.4 V dc; 12 V dc is 10.8 - 13.2 V dc and 5 V dc is 4.75 - 5.5 V dc
• Built-in EMI filter
• LED power-on indicator
• 2-year manufacturer warranty
Note
De-rating below 0 and above 40°C.
Specifications
Attribute | Value |
---|---|
Output Voltage | 12V dc |
Input Voltage Range | 18 → 36 V dc |
Power Rating | 15W |
Input Voltage Nominal | 24 V dc |
Output Current | 1.25A |
Mounting Type | Chassis Mount |
Isolated | Yes |
Number of Outputs | 1 |
Output Voltage Adjustment Range | 10.8 → 13.2V |
Isolation Voltage | 2kV ac |
Width | 51mm |
Length | 78mm |
Depth | 28mm |
Load Regulation | ±0.3% |
Maximum Temperature | +60°C |
Efficiency | 76% |
Minimum Temperature | -10°C |
Standards Met | 3, 4, 5, 6, 8, EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A |
